HP ProBook 6555b User Manual

2. Insert the card into the Media Card Reader, and then push in on the card until it is firmly seated.
You will hear a sound when the device has been detected, and a menu of available options may
be displayed.
Removing a digital card
CAUTION: To prevent loss of data or an unresponsive system, use the following procedure to safely
remove the digital card.
1. Save your information and close all programs associated with the digital card.
NOTE: To stop a data transfer, click Cancel in the operating system Copying window.
2. To remove a digital card:
a. Click the Safely Remove Hardware and Eject Media icon in the notification area, at the far
right of the taskbar.
NOTE: To display the Safely Remove Hardware and Eject Media icon, click the Show
hidden icons icon (the arrow at the left side of the notification area).
b. Click the name of the digital card in the list.
NOTE: You are prompted that it is safe to remove the hardware device.
3. To eject the digital card, press in on the card (1), and then remove it from the slot (2).
Using Media Card Reader cards 103

HP ProBook 6555b Specifications

General

Graphics	ATI Mobility Radeon HD 4250
Chipset	AMD M880G
Processor	AMD Turion II, AMD Athlon II
Display	15.6-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
Memory	Up to 8 GB DDR3 SDRAM
Storage	320 GB, 250 GB, or 160 GB 7200 rpm SATA II HDD
Operating System	Genuine Windows 7 Professional, FreeDOS
Battery	6-cell lithium-ion
Optical Drive	DVD+/-RW SuperMulti DL
Networking	Gigabit Ethernet, Wi-Fi 802.11a/b/g/n, Bluetooth
Audio	High Definition Audio, stereo speakers, microphone
Ports	3 USB 2.0, VGA, HDMI, RJ-45, headphone/microphone combo jack
Card Reader	5-in-1
Webcam	2 MP Webcam (optional)
