HP ProBook 6555b User Manual

Replacing a hard drive in the hard drive bay
CAUTION: To prevent information loss or an unresponsive system:
Shut down the computer before removing the hard drive from the hard drive bay. Do not remove the
hard drive while the computer is on, in the Sleep state, or in Hibernation.
If you are not sure whether the computer is off or in Hibernation, turn the computer on by briefly pressing
the power button. Then shut down the computer through the operating system.
To remove a hard drive:
1. Save your work.
2. Shut down the computer and close the display.
3. Disconnect all external hardware devices connected to the computer.
4. Unplug the power cord from the AC outlet.
5. Turn the computer upside down on a flat surface, with the battery bay toward you.
6. Remove the battery from the computer.
7. Loosen the 2 hard drive cover screws (1).
8. Remove the hard drive cover (2).
9. Loosen the hard drive screws (1).
10. Pull the hard drive tab to the right (2) to disconnect the hard drive.
Replacing a hard drive in the hard drive bay 85

HP ProBook 6555b Specifications

General

Graphics	ATI Mobility Radeon HD 4250
Chipset	AMD M880G
Processor	AMD Turion II, AMD Athlon II
Display	15.6-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
Memory	Up to 8 GB DDR3 SDRAM
Storage	320 GB, 250 GB, or 160 GB 7200 rpm SATA II HDD
Operating System	Genuine Windows 7 Professional, FreeDOS
Battery	6-cell lithium-ion
Optical Drive	DVD+/-RW SuperMulti DL
Networking	Gigabit Ethernet, Wi-Fi 802.11a/b/g/n, Bluetooth
Audio	High Definition Audio, stereo speakers, microphone
Ports	3 USB 2.0, VGA, HDMI, RJ-45, headphone/microphone combo jack
Card Reader	5-in-1
Webcam	2 MP Webcam (optional)
