A-1
A
Switch Specifications
Physical
Electrical
■ Power adapter module (5188-6700) specifications:
■ PoE PD connection to Port 1
Port 1 is an IEEE 802.3af Compatible PD (PoE Powered Device) - Class 3
Environmental
Width: 19.6 cm (7.7 in)
Depth: 13.4 cm (5.3 in)
Height: 4.4 cm (1.73 in)
Weight: 0.54 kg (1.19 lbs)
AC Input Voltage: 100-240 V
Maximum AC Input Current: 0.5 A
AC Input Frequency Range: 50-60 Hz
DC Input Voltage: 12 ± 10% volts
Maximum DC Input Current: 1.25 A
Operating Non-Operating
Temperature: 0 °C to 40 °C (32 °F to 104 °F) -40 °C to 70 °C (-40 °F to 158 °F)
Relative humidity:
(non-condensing)
15% to 95% at 40 °C (104 °F) 15% to 90% at 65 °C (149 °F)
Maximum altitude: 3048 m (10,000 ft) 3048 m (10,000 ft)
