HP ProLiant DL320 User Manual

Server component identification 13
Item Description Item Description
15 Power connector
* Designations if the optional PCI riser board is installed.
System maintenance switch
Position Default Function
S1 Off Reserved
S2 Off Off = Normal operation
On = RBSU will not commit any
configuration changes *
S3 Off Reserved
S4 Off Off = Normal operation
On = Override RBSU setting and
enable diskette boot *
S5 Off Off = Power-on password enabled
On = Power-on password disabled *
S6 Off Off = Normal operation
On = BIOS will clear CMOS and
NVRAM *
S7 Off Reserved
S8 Off Reserved
* "On" activates the function.

HP ProLiant DL320 Specifications

General

Product Line	ProLiant
CPU Type	Intel Xeon
Storage	Up to 4 LFF (3.5") or 8 SFF (2.5") SAS/SATA/SSD drives (depending on model and configuration)
Network	Embedded 1GbE
Power Supply	Single or Redundant Power Supplies (depending on model and configuration)
Form Factor	1U
Server Type	Rack Server
