HP ProLiant DL585 User Manual

Installing hardware options
HP ProLiant DL585 Server User Guide 4-5
Upgrading processor memory boards
To upgrade to a single core 2.6 GHz processor or later or a dual core processor
configuration:
1. Power down the server. Refer to “Powering down the server” in Chapter 2,
“Server operations.”
2. Extend the server from the rack. Refer to “Extending the server from the rack” in
Chapter 2, “Server operations.”
3. Remove the access panel. Refer to “Removing the access panel” in Chapter 2,
“Server operations.”
4. Remove all the processor memory boards and air baffles.
NOTE: Do not discard the air baffle. Store it for possible future use.
5. Remove the front fan cage.
Figure 4-3: Removing the front cage
