Figure 4-9 Appearance of the outdoor AC power cable
Table 4-26 Technical specifications of the outdoor AC power cable
Parameter
Description
Color Black (cores are brown, blue, or yellow green)
Cross-sectional area of the conductor
3 x 1.50 mm
2
Note: The specifications of AC power cables are different in different countries and regions.
The AC power cable that complies with the China national standard is used as an example
here.
Indoor AC Power Cables
Indoor AC power cables are used to provide external power supplies for the ATN 905 device.
Figure 4-10 shows the appearance of the AC power cable used for an indoor ATN 905 device
and Table 4-27 lists the technical specifications of the AC power cable.
ATN 905 Multi-service Access Equipment
Product Description 4 Hardware Structure
Issue 01 (2013-05-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
50
