Appearance Type Description
FC/PC connector Round fiber connector/protruding
polished
ST/PC connector Square fiber connector/protruding
polished
Outdoor Optical Fibers
Outdoor ATN 905 devices must use outdoor optical fibers when installed outdoors. Figure
4-17 shows the appearance of an outdoor optical fiber.
Figure 4-17 Appearance of an outdoor optical fiber
Outdoor optical fibers used by ATN 905 devices are multi-mode optical fibers that use DLC/
PC connectors at both ends.
NOTE
DLC is short for Duplex LC.
4.5 Equipment Support
ATN 905 can work with various equipment to implement various applications.
ATN 905 Multi-service Access Equipment
Product Description 4 Hardware Structure
