Huawei NE40E-X1 User Manual

Indicator/
Button
Description
USB indicator If the indicator is steady green, it indicates that a mobile storage device
is identified.
If the indicator blinks green, it indicates that a mobile storage device is
being accessed or written.
If the indicator is steady red, it indicates that a mobile storage device
cannot be identified or fails to be accessed or written.
If the indicator is off, it indicates that no mobile storage device is
connected to the USB interface.
ETH LINK
indicator
If the indicator is steady green, it indicates that the ETH link is Up.
If the indicator is off, it indicates that the ETH link is Down.
ETH ACT
indicator
If the indicator blinks yellow, it indicates that data is being transmitted.
If the indicator is off, it indicates that no data is being transmitted.
RST button The button is used for resetting the MPUG. Pressing the RST button
resets the MPUG.
Table 1-10 Interfaces on the MPUG
Interface
Name
Interface Type Description
ETH interface
(10M/100M/
1000M Base-
TX auto-
sensing)
RJ45 One ETH interface, for system maintenance
Console
interface
RJ45 One console interface, used to connect to the
console for on-site configuration
AUX interface RJ45 One AUX interface, used to connect to the
modem for remote maintenance through a
dial-up connection
USB interface USB 2.0 One USB interface (USB 2.0 host interface),
for software upgrade
BITS clock
interface
RJ45 Two RJ45 interfaces, used to input 1588v2
time signals
RS485 interface RJ45 Used to connect to the monitoring interface
on the external AC power supply module
l Attributes of the interfaces on the MPUG
Table 1-11 lists the USB interface attributes.
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 1 NE40E-X1 Hardware Description
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
16
