Huawei NE40E-X1 User Manual

Table 1-11 Attributes of the USB interface
Attribute Description
Connector type USB
Working mode High-speed or full-speed
Standard
compliance
USB 2.0
Table 1-12 lists the 10Base-T/100Base-TX/1000Base-T-RJ45 interface attributes.
Table 1-12 Attributes of the 10Base-T/100Base-TX/1000Base-T-RJ45 interface
Attribute Description
Connector type RJ45
Working mode 10M/100M/1000M auto-sensing, half-duplex or full-duplex
Standard
compliance
IEEE 802.3-2002
Cable
specification
Category 5 unshielded twisted pair (UTP) cables recommended in the case
of 10 Mbit/s or 100 Mbit/s; super category 5 Shielded Twisted Pair (STP)
cables recommended in the case of 1000 Mbit/s
Table 1-13 lists the console interface attributes.
Table 1-13 Attributes of the console interface
Attribute
Description
Connector type RJ45
Working mode Duplex Universal Asynchronous Receiver/Transmitter (UART)
Electrical
characteristics
RS-232
Baud rate 9600 bit/s (default value), which is configurable
Data equipment
type
Data Circuit-terminating Equipment (DCE)
Cable
specification
8-core shielded cable
Table 1-14 lists the AUX interface attributes.
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 1 NE40E-X1 Hardware Description
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
17
