Table 2-13 Attributes of the console interface
Attribute Description
Connector type RJ45
Working mode Duplex Universal Asynchronous Receiver/Transmitter (UART)
Electrical
characteristics
RS-232
Baud rate 9600 bit/s (default value), which is configurable
Data equipment
type
Data Circuit-terminating Equipment (DCE)
Cable
specification
8-core shielded cable
Table 2-14 lists the AUX interface attributes.
Table 2-14 Attributes of the AUX interface
Attribute
Description
Connector type RJ45
Working mode Duplex UART
Electrical
characteristics
RS-232
Baud rate 9600 bit/s (default value), which is configurable
Data equipment
type
DTE (Data Terminal Equipment)
Cable
specification
8-core shielded cable
Table 2-15 lists the external clock interface attributes.
Table 2-15 Attributes of the external clock interface
Attribute
Description
Connector type RJ45
Cable
specification
120-ohm clock cable
Standard
compliance
G.703
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 2 NE40E-X2 Hardware Description
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
39
