Huawei NE40E-X1 User Manual

Table 3-1 Functions of the indicators on the 8-Port 100/1000Base-X-SFP High-speed Interface
Card (HIC)
Indicator Description
STAT If the indicator is steady green, it indicates that the FPIC works normally.
If the indicator is off, it indicates that the FPIC is powered off or is not
registered.
If the indicator is steady red, it indicates that the hardware on the FPIC
is faulty.
If the indicator is steady yellow, it indicates that the FPIC is installed in
a slot for a HIC and an alarm is reported or the FPIC is not loaded with
the logic.
LINK/ACT
(green)
If the indicator is steady on, it indicates that the link is normal.
If the indicator blinks, it indicates that data is being transmitted.
If the indicator is off, it indicates that the link is Down.
Interface Attributes
Table 3-2 lists the attributes of the interfaces on the 8-Port 100/1000Base-X-SFP High-speed
Interface Card (HIC).
Table 3-2 Attributes of the interfaces on the 8-Port 100/1000Base-X-SFP High-speed Interface
Card (HIC)
Attribute
Value
Connector LC/PC
Interface attributes Determined by the selected SFP optical module
Working mode Full-duplex
Standard
compliance
IEEE 802.3-2002
Frame format Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol IP
Table 3-3 Attributes of the 100 M SFP optical module
Attribute
Value
Maximum
transmission
distance
2 km ( 1.24
mi. )
15 km ( 9.32
mi. )
40 km ( 24.86
mi. )
80 km ( 49.71
mi. )
Center wavelength 1310 nm 1310 nm 1310 nm 1550 nm
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 3 Boards
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
44
