Panel Description
Table 3-20 describes the indicators on the 8-Port 100Base-RJ45 Flexible Interface Card (FIC,
Supporting 1588v2).
Table 3-20 Indicators on the 8-Port 100Base-RJ45 Flexible Interface Card (FIC, Supporting
1588v2)
Indicator Meaning
STAT If the indicator is steady on, it indicates that the TND1EF8T works
normally.
If the indicator is off, it indicates that the TND1EF8T is not powered on
or fails to be registered.
If the indicator is steady red, it indicates that the hardware of the
TND1EF8T is faulty.
If the indicator is steady yellow, it indicates that the FPIC is not loaded
with the logic.
Interface Attributes
Table 3-21 lists the interface attributes of the 8-Port 100Base-RJ45 Flexible Interface Card (FIC,
Supporting 1588v2).
Table 3-21 Interface attributes of the 8-Port 100Base-RJ45 Flexible Interface Card (FIC,
Supporting 1588v2)
Attribute
Value
Connector RJ45
Working mode Full-duplex
Standard
compliance
IEEE 802.3-2002
Frame format Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol IP
Specifications
Table 3-22 lists the technical specifications of the 8-Port 100Base-RJ45 Flexible Interface Card
(FIC, Supporting 1588v2).
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 3 Boards
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
57
