Huawei NE40E-X2 User Manual

Connector
Pin
Color Relati
on
Description
ALMI Interface
Cable
ALMO Interface
Cable
5 White-blue Ground for alarm input
3
Negative of alarm
concatenation 1
7 White-
brown
Twiste
d pair
Alarm input 4 Positive of alarm
concatenation 2
8 Brown Ground for alarm input
4
Negative of alarm
concatenation 2
4.9.3 Technical Specifications
Technical Specifications
Table 4-22lists the technical specifications of the alarm input/output cable.
Table 4-22 Technical specifications of the alarm input/output cable
Item
Specification
Connector X1 Network Interface Connector, 8-Bit 8PIN, Crystal Model Connector
Cable type Twisted-Pair Cable, 100 ohm, Category 5e, 0.52 mm, 24AWG, 8 Cores, 4
Pairs, PANTONE 430U
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 4 Cables
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
92
