Table 3-7 Specifications of the8-Port 100/1000Base-X-SFP High-speed Interface Card (HIC)
Feature Description
Supported protocol and
service
IEEE 802.3x traffic control
IEEE 802.1q, jumbo frames supported by VLAN
IEEE 802.3ad link aggregation
IEEE 802.1p label
Interface type SFP LC optical interface
Reliability and availability Hardware features
l Hot-swappable
NMS Enhanced command line management interfaces
SNMP and MIB
Operating environment Long-term operating temperature: -5°C to 50°C ( 23°F to 122°
F )
Short-term operating temperature: -20°C to +60°C ( -4°F to
140°F )
Long-term relative humidity: 5% to 85%
Short-term relative humidity: 5% to 95%
Storage environment
Storage temperature: -40°C to +70°C ( -40°F to 158°F )
Storage humidity: 0% to 95%
3.2 8-Port 100/1000Base-X-SFP High-speed Interface Card A
(HIC, Supporting 1588v2)
Overview
The 8-Port 100/1000Base-X-SFP High-speed Interface Card A (HIC, Supporting 1588v2)
provides eight GE interfaces and supports the 1588v2 function and synchronization Ethernet.
The E8GFA supports the following types of optical modules:
l GE optical module, providing features of GE optical interfaces
l FE optical module, providing features of FE optical interfaces
l Electrical-interface SFP module, providing features of 100M/1000M auto-sensing
electrical interfaces When the The 8-Port 100/1000Base-X-SFP High-speed Interface Card
A (HIC, Supporting 1588v2) is installed with an electrical-interface SFP module or O/E
converter, the 1588v2 function and synchronization Ethernet are not supported.
l The 8-Port 100/1000Base-X-SFP High-speed Interface Card A (HIC, Supporting 1588v2)
supports the mixed use of the three types of modules.
Figure 3-2 shows the outline of the 8-Port 100/1000Base-X-SFP High-speed Interface Card A
(HIC, Supporting 1588v2).
