Table D-12 Specifications of 1 Gbit/s Electrical Transceivers
Parameter Unit Value Remarks
Interface standard - 1000BASE-T -
Transmission rate Mbit/s 10-1000 Complying with
IEEE802.3
Interface type - RJ-45
Transmission
distance
m 100 ( 328.08 ft ) Category 5 UTP,
BER < 10
-10
, (GBIC/
RJ45-GE-100)
Category 5 UTP,
BER < 10
-12
, (SFP/
RJ45-GE-100)
Table D-13 Applications of 1 Gbit/s electrical transceivers
Product Model BOM Number Applications
GBIC/RJ45-GE-100m 34100044 1.25 Gigabit Ethernet over Cat 5 cable
SFP/RJ45-GE-100m 34100052
l Switch to switch interface
l Switched backplane applications
l File server interface
SFP/RJ45-GE-100m 34100080
l Switch to switch interface
l Switched backplane applications
l File server interface
D.4 1.25 Gbit/s SFP/eSFP Optical Module
The 1.25 Gbit/s SFP/eSFP optical modules of different levels can be applied to the GE interface .
The wavelength of the common 1.25 Gbit/s SFP/eSFP optical modules can be 850 nm, 1310
nm, or 1550 nm and the transmission distance ranges from 0.5 ( 0.31 mi. ) km to 100 km ( 62.14
mi. ). The wavelength of the 1.25 Gbit/s SFP/eSFP CWDM optical module ranges from 1470
nm to 1610 nm and the transmission distance is 70 km.
Table D-14 lists the currently available 1.25 Gbit/s SFP/eSFP optical modules.
