l Queries about alarm prompts, alarm indications, running status, and alarm status of PSUs
l Queries about alarm prompts, alarm indications, running status, and alarm status of the
voltage and ambient temperature
1.1.4 System configuration
Table 1-1 System configuration list of the NE40E-X1
Item Description
Processing unit Main frequency: 1.3GHz
SDRAM 2 GB
Flash 32 MB
CF card 1 GB
Switching capacity 20 Gbit/s (bidirectional)
Interface capacity 52 Gbit/s
Number of NPU slots 1
Number of PIC slots 4
Number of MPU slots 2
Maximum port rate supported by
PICs or NPU
10 Gbit/s
1.1.5 Main Parts of the NE40E-X1
The NE40E-X1 has an integrated chassis with main parts that all support hot swapping.
Figure 1-3 shows the outline and parts of the NE40E-X1.
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 1 NE40E-X1 Hardware Description
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4
