C.1 Interface Attributes of 100Base-TX/1000Base-T-RJ45
Table C-1 lists the interface attributes of 100Base-TX/1000Base-T-RJ45.
Table C-1 Interface attributes of the 100Base-TX/1000Base-T-RJ45
Attributes Description
Connector type RJ45
Working mode 100M/1000M auto-sensing and half-duplex and full-duplex
Cable specification When the interface rate is 1000 Mbit/s, Category 5 unshielded
twisted pair (UTP) cable is recommended. When the interface rate
is 1000 Mbit/s, Super category 5 Shielded Twisted Pair (STP) cable
is recommended.
Frame format Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol IP
C.2 Interface Attributes of 1000Base-X-SFP
Table C-2 lists the interface attributes of 1000Base-X-SFP.
Table C-2 Interface attributes of the 1000Base-X-SFP
Attributes
Description
Connector type LC/PC
Interface attributes Compliant with the selected SFP optical module. (For the attributes
of SFP modules, see Table C-3 and Table C-4.)
Working mode Full-duplex
Compliant standard IEEE 802.3-2002
Frame format Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol IP
Table C-3 Attributes of 1000M SFP optical modules
Attributes
Description
Transmission
distance
0.55 km
(0.31 mi)
10 km
(6.21 mi)
40 km
(24.86
mi)
40 km
(24.86
mi)
80 km
(49.71
mi)
100 km
(62.14
mi)
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description C List of Interface Attributes
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
106
