2. Read the content in the dialog box carefully, and select I have read and understood the
consequences associated with performing this operation..
3. Click OK.
The Execution Result page is displayed.
4. On Execution Result page, check whether remote replication pair is created
successfully.
5. Click Close.
The remote replication pair displays detailed information in the remote replication pair
list if successfully created.
----End
3.6.4 Creating an Asynchronous Remote Replication (Applicable
to V300R006C10)
Creating an asynchronous remote replication includes the following operations: configuring
basic information about the remote replication, selecting a primary resource and a secondary
resource, and setting remote replication properties. You can proceed as prompted.
Prerequisites
l The remote replication license is valid.
l The local and remote storage devices must support remote replication.
l The remote storage device is added already, and secondary LUN is created on the remote
device.
l The storage capacities of primary and secondary LUNs are the same.
l The statuses of primary and secondary LUNs are healthy.
l The primary and secondary LUNs have not configured any feature that conflicts with the
remote replication feature.
Procedure
Step 1 Log in to DeviceManager.
Step 2 Choose
Data Protection > Remote Replication > Remote Replication Pair.
Step 3 Click Create.
The Create Remote Replication Pair dialog box is displayed.
Step 4 Specify the replication mode and resource type for remote replication.
1. Set Replication Mode to Synchronous.
2. Select a primary resource type from the drop-down list.
Possible values of the primary resource type are LUN, Microsoft Exchange, VMware,
Hyper-V, Oracle and SQL Server.
3. Optional: When Microsoft Exchange, VMware, Hyper-V, Oracle or SQL Server is
selected as the primary resource type, click Select, select an application instance, and
click OK.
OceanStor V3 Series
Remote Replication Feature Guide for Block
3 Configuring Remote Replication
Issue 06 (2018-01-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
56
