Figure 7-6 Login
7.1.4 Operations Related to the Advanced User
If you log in to the app as Advanced User, you can set grid parameters, protection
parameters, and feature parameters for the SUN2000.
7.1.4.1 Setting Grid Parameters
Procedure
Step 1 Choose Function Menu > Settings > Grid Parameters to access the parameters
setting screen.
Figure 7-7 Grid parameters (advanced user)
----End
Parameters
No.
Parameter Description
1 Grid Code Set this parameter based on the grid code of the country or
region where the inverter is used and the inverter application
scenario.
2 Isolation settings Set the working mode of the inverter based on the grounding
status at DC side and the connection to the power grid.
SUN2000-(196KTL-H0, 200KTL-H2, 215KTL-H0)
Series
User Manual 7 Man-Machine Interactions
Issue 07 (2021-07-08) Copyright © Huawei Technologies Co., Ltd. 60
