4.5 Installing the SUN2000L
Procedure
Step 1 Hold the handles on both sides of the SUN2000L, lift the SUN2000L from the packing case,
and move it to the installation position.
To prevent device damage and personal injury, keep balance when moving the SUN2000L.
Do not use the ports and wiring terminals at the bottom to support any weight of the
SUN2000L.
When you need to temporally place the SUN2000L on the ground, use foam, paper or
other protection material to prevent damage to its cover.
Figure 4-15 Moving a SUN2000L
Step 2 Install the SUN2000L on the mounting bracket and align the SUN2000L enclosure with the
mounting bracket.
If the bottom of the mounting plate does not snap into place, push the SUN2000L from the
front until the bottom of the mounting plate snaps into the mounting bracket.
