SUN2000L-(4.125KTL, 4.95KTL)-JP
User Manual
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6.4.1 Embedded WebUI
Prerequisites
The SmartLogger1000 has connected to the PC.
This section uses the WebUIs for SmartLogger V100R001C00SPC111 as an example. The data on the
WebUI snapshots is for reference only.
Procedure
Step 1 Enter https://XX.XX.XX.XX in the address box of the browser, and press Enter. The login
page is displayed, as shown in Figure 6-1.
Figure 6-1 WebUI login page
XX.XX.XX.XX is the IP address for the SmartLogger1000. The default IP address is 192.168.0.10.
Step 2 Specify Language, User Name, and Password, and then click Log In.
Because of the permission restriction, log in as Advanced User or Special User.
For the SmartLogger software versions that are SmartLogger V100R001C00SPC111 and later, the
initial password is Changeme.
Use the initial password upon first power-on and change it immediately after login. To ensure
account security, change the password periodically and keep the new password in mind. Not
changing the initial password may cause password disclosure. A password left unchanged for a long
period of time may be stolen or cracked. If a password is lost, devices cannot be accessed. In these
cases, the user is liable for any loss caused to the PV plant.
If you enter wrong passwords for six consecutive times in 5 minutes, your account will be locked out.
You have to try again with the account 10 minutes later.
