WA603DE & WA653DE
Fat AP Configuration Guide 3 Service Configuration
Issue 02 (2012-04-19) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
18
3. Select 802.1X.
The page shown in Figure 3-13 is displayed.
Figure 3-13 Configuring 802.1X authentication
Table 3-6 Description of the parameters for 802.1X authentication
Parameter Description
Radius NAS-ID ID allocated by the Radius server.
Authentication Server **
Required **
Information about the authentication server (mandatory).
Enter the IP address, port number, and server key that are
obtained from the carrier in the IP address, Port, and
Server Secret fields.
Accounting Server **
Optional **
Information about the accounting server (optional).
If the carrier does not provide the settings, you do not need
to set the parameters.
4. Click Update Settings to save the settings.
----End
3.3.5 Operation Result
Choose Status > Radio 2.4G (or Radio 5G) from the left navigation tree, click a Wireless #
tab, and view the radio settings, as shown in Figure 3-14.
