WA603DE & WA653DE
Fat AP Configuration Guide 4 Upgrade and Maintenance
Issue 02 (2012-04-19) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
27
4.4.2 Uploading Logs to an FTP or TFTP Server
To upload the current log information to a specified FTP or TFTP server, proceed as follows:
1. Choose Maintenance > Support Info from the left navigation tree.
The page shown in Figure 4-6 is displayed.
Figure 4-6 Uploading logs to an FTP or TFTP server
2. Select FTP in the Transfer Method field and set the parameters in the FTP Options area
according to Table 4-4.
Table 4-4 describes the parameters for uploading logs to an FTP or TFTP server.
Table 4-4 Parameters for uploading logs to an FTP or TFTP server
Parameter Description
Transfer Method Logs can be transferred to an FTP or TFTP server or saved to the
local computer.
Server Address IP address of the FTP or TFTP server.
Filename Name of the log file. The log file must be in TXT format. The file
path can contain "\" or "/" but the file name cannot contain "\" or "/".
In addition, the file name cannot start with a period (.) and cannot
exceed 255 characters.
Username User name used to log in to the FTP server.
Password Password used to log in to the FTP server.
3. Click Upload Now to save the settings.
