INSTALLATION
3.6 Installation of the guide wire
The guide wire is a wire that is laid from the charging
station towards, for instance, a remote part of the working
area or through a narrow passage to be then connected
with the boundary loop. The same cable roll is used for
both the boundary loop and guide wire.
The guide wire is used by the robotic lawnmower to nd
its way back to the charging station but also to guide the
robotic lawnmower to hard-to reach areas of the garden.
Run the robotic lawnmower at varying distances from the
guide wire to reduce the risk of tracks forming. The area
beside the wire which the robotic lawnmower then uses
is called the Corridor. The wider the corridor allowed by
the installation, the less the risk of tracks forming. When
installing, it is therefore important to create as much free
space as possible along the guide wire.
The robotic lawnmower always runs to the left of the
guide wire as seen facing the charging station. Thus the
corridor is to the left of the guide wire. When installing,
it is therefore important to create as much free space as
possible to the left of the guide wire, as seen facing the
charging station. It is not allowed to lay the guide wire
closer than 30 cm from the boundary wire.
The guide wire, as the boundary wire, can be pegged
on or buried in the ground.
IMPORTANT INFORMATION
Make sure to have as much free space
as possible to the left of the guide wire,
as seen facing the charging station.
