WORK SECTION TYPE - AUSFÜHRUNG DER WEGEVENTILSEKTION
48
HCD3M-04
HC-D3M
37
Sectional Valve - WEGEVENTIL IN SEKTIONSBAUWEISE
Ausführung der WegeventilsektionWork section identification
GewindeausführungenThread type
SERVICE PORTS - ANSCHLÜSSE (A - B)
Parallel circuit section
Parallelkreislaufsektion
DESCRIPTION - BESCHREIBUNG ORDERING CODES - BESTELLBEZEICHNUNGEN
RP
Series circuit section
Serienkreislaufsektion
RS
Tandem circuit section
Tandemkreislaufsektion
RT
U03G04 M01
PORT
ANSCHLUSS
(A)
PORT
ANSCHLUSS
(B)
