Hypertherm Powermax 85 Service Manual

Torch SeTup
3-52 powermax 65/85 Service Manual
45A Unshielded Air flow rate - slpm/scfh
Mild Steel
Hot 147 / 310
Cold 210 / 450
Metric
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
0.5
1.5 3.8 250
0.0
9000 120 12500 120
1 9000 120 10800 121
1.5 0.1 7700 120 10200 121
2 0.3 6150 119 7800 122
3
0.4
3950 121 4900 123
4 2350 123 3560 124
6 0.5 1400 126 2050 124
English
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
in in % seconds ipm Volts ipm Volts
26GA
0.06 0.15 250
0.0
350 120 500 120
22GA 350 120 450 120
18GA
0.1
350 119 400 121
16GA 300 121 400 121
14GA 0.2 250 119 320 122
12GA
0.4
200 120 216 123
10GA 100 123 164 124
3/16 in 0.5 85 122 108 124
1/4 in 0.6 48 127 73 124
