How to improve cut quality on Hypertherm Powermax 85?
If the cut quality is poor with your Hypertherm Welding System, verify that the torch is being used correctly. Inspect the consumables for wear and replace them if necessary. Check the air pressure and air quality. Also, verify that the cutting mode switch is in the proper position for the cutting operation and that the correct consumables are installed.
What to do if the arc blows out on Hypertherm Powermax 85 Welding System?
If the arc of your Hypertherm Welding System blows out but re-ignites when you press the torch trigger again, inspect the consumable parts and replace them if they are worn or damaged. Replace the gas filter’s element if it is contaminated and make sure the gas pressure is at the proper level.
What to do if the arc does not transfer to the workpiece with Hypertherm Powermax 85 Welding System?
If the arc does not transfer to the workpiece with your Hypertherm Welding System, clean the area where the work clamp contacts the workpiece to ensure a good metal-to-metal connection. Inspect the work clamp for damage and repair as necessary. The pierce-height distance may be too large, so move the torch closer to the workpiece and try firing the torch again.
General| Gas Supply | Clean, dry, oil-free air or nitrogen |
|---|---|
| Cooling Method | Fan-cooled |
| Input Voltage | 200-600V, 3-phase |
| Current Output | 25-85 A |
| Duty Cycle | 60% @ 85 A |
| Recommended Gas Inlet Flow Rate/Pressure | 6.7 scfm @ 85 psi |
| Cutting Capacity (Recommended) | 1" (25 mm) |
| Gas Type | Air/Nitrogen |
Outlines warranty periods for power supplies, torches, and components.
Details electrical ratings for Powermax65 (voltage, current, duty cycle, power factor).
Provides cutting capacities, speeds, and gouging rates for Powermax65/85.
Provides cut charts and kerf-width compensation data for various applications.
Describes the front and rear controls, LEDs, and status screen of the power supply.
Guides on connecting power, gas, torch, and attaching work leads/clamps.
Explains gas pressure, current adjustments, and duty-cycle limitations.
Covers safety trigger, cutting hints, starting cuts, piercing, gouging, and faults.
Details machine torch setup, cut quality optimization, piercing, and common faults.
Covers controls, theory of operation, sequence, prep, and procedures for troubleshooting.
Details inspections, resistance checks, fault codes, icons, and solutions.
Outlines tests for voltage input, DC power buss, diodes, sensors, flyback circuit, and switches.
Presents electrical schematic diagrams for CSA and CE configurations.
