Hypertherm Powermax 85 Service Manual

TroubleshooTing and sysTem TesTs
powermax 65/85 Service Manual 5-15
Legend
1. Collector 1 (C1)
2. Emitter 2 (E2)
3. Collector 2, Emitter 1 (C2,E1)
4. Gate 1 (G1)
5. Emitter 1 (E1)
6. Emitter 2 (E2)
7. Gate 2 (G2)
9 VDC
battery
R4
2.0K
009036
Normally open
(N.O.) pushbutton
switch
Yellow
Minigrabber
test clip
R1
3.01M
009464
Black
Minigrabber
test clip
Q1
150 A
1400 V
109125
R3
2.0K
009036
Red LED lamp
109092
Red Minigrabber
test clip
D1
1
2
3
5
6
7
Schematic for building an IGBT tester
4
