Hypertherm Powermax 85 Service Manual

Parts
powermax 65/85 Service Manual 7-25
Part number Description
228648 Kit: Powermax65 output inductor
228665 Kit: Powermax85 output inductor
228688 Kit: Powermax65 and Powermax85 pressure switch
228687 Kit: Powermax65 and Powermax85 regulator (solenoid valve)
228686 Kit: Powermax65 and Powermax85 fan subassembly
228685 Kit: Powermax65 and Powermax85 air filter
058519 O-ring: VITON .673X.063
228954 Kit: Duramax 75°/HRT torch handle replacement
228955 Kit: Duramax 15°/HRTs torch handle replacement
075714 Handle screws, #4 x 1/2 slotted TORX pan head, S/B
228721 Kit: Duramax 75°/15° hand torch safety trigger with spring replacement
228719 Kit: Duramax 75° hand torch cap-sensor switch replacement
228109 Kit: Powermax30/45/65/85/105 15° hand torch/T30v/T45v/HRTs cap-sensor switch
replacement
059473 Powermax65/85/105 75° hand torch assembly with 7.6m (25 ft) lead
059474 Powermax65/85/105 75° hand torch assembly with 15m (50 ft) lead
059470 Powermax65/85/105 15° hand torch assembly with 7.6m (25 ft) lead
059471 Powermax65/85/105 15° hand torch assembly with 15m (50 ft) lead
228959 Kit: Duramax hand torch lead replacement, 7.6m (25 ft)
228960 Kit: Duramax hand torch lead replacement, 15m (50 ft)
059477 Powermax65/85/105 180° full-length machine torch assembly with 7.6m (25 ft) lead
059478 Powermax65/85/105 180° full-length machine torch assembly with 10.7m (35 ft) lead
059479 Powermax65/85/105 180° full-length machine torch assembly with 15m (50 ft) lead
059482 Powermax65/85/105 180° mini machine torch assembly with 7.6m (25 ft) lead
059483 Powermax65/85/105 180° mini machine torch assembly with 10.7m (35 ft) lead
059484 Powermax65/85/105 180° mini machine torch assembly with 15m (50 ft) lead
