PARKING BRAKE
2. SPECIFICATION
DISK BRAKE
There are two brake systems, the foot brake system and the hand brake system.
In the foot brake system, oil pressure is generated in the master cylinder by treading on the brake
pedal. This pressure causes the wheel cylinder pistons to extend, expanding the brake shoes and
pressing them against the brake drums to attain braking force.
In the hand (parking) brake system, the brake shoes are expanded by operating the brake lever.
Force from the lever is transmitted to the brake shoes through the hand brake cables and a lever
arm in each disk brake assembly.
4-1
GROUP 1 STRUCTURE AND FUNCTION
SECTION 4 BRAKE SYSTEM
1. OUTLINE
1)
2)
Item
Type
Parking lever stroke
Parking cable stroke
Ratchet, internal expanding mechanical type
295
mm
(11.6
in
)
28
mm
(1.1
in
)
Specification
Item
Type
Master cylinder diameter
Pedal adjustment
Brake oil
Azola ZS10 (SAE 10W hydraulic oil)
Wet disk brake
Pedal height
Play
40
mm (
1.6
in)
153
~
163
mm (
6.0
~
6.4
in)
13
~
18
mm (
0.5
~
0.7
in)
Specification
