Appendix C. Specifications
Physical specifications
Width 146.0 mm (5.75 in.) without bezel
148.3 mm (5.84 in.) with bezel
Length 205.5 mm (8.09 in.) without bezel
210.5 mm (8.29 in.) with bezel
Height 82.5 mm (3.25 in.) without bezel
84.8 mm (3.34 in.) with bezel
Weight (without a cartridge) 3 kg (6 lb 10 oz)
Power specifications
Power measurements SAS drive
Idle Mode (no cartridge) 12.5 W
Idle Mode (cartridge loaded) 14.5 W
Reading and writing (at 4.1 m/s) 22.0 W
Environmental specifications
Environmental factor Operating Storage Shipping
Drive temperature 10°C to 40°C (50°F to 104°F) -40°C to 60°C
(-40°F to 140°F)
-40°C to 60°C (-40°F to 140°F)
Relative humidity 20% to 80%
26°C wet bulb maximum
10% to 90%
noncondensing
10% to 90% noncondensing
Drive temperature and relative humidity are measured in front of the bezel, near
the air intake area (see Figure 4 on page 6).
Other specifications
Maximum altitude 3048 m (10 000 ft) for operating and storage
12 192 m (40 000 ft) for shipping
Cartridge extraction force 250 to 750 gm
© Copyright IBM Corp. 2011 65
