Dimensions and weight
Ensure space is available in a rack, capable of supporting the enclosure based on
the data shown in Table 28.
Table 28. Physical characteristics
Enclosure Height Width Depth
Maximum weight
Drive ready
(without drive
modules)
Fully
configured
(with drive
modules)
2076-112, 2076-212, and
2076-312 Control Enclosures
with 12 drive slots
87.9 mm
(3.46 in.)
483 mm
(19.0 in.)
630 mm
(24.8 in.)
17.1 kg
(37.6 lb)
27.2 kg
(59.8 lb)
2076-124, 2076-224, and
2076-324 Control Enclosures
with 24 drive slots
87.9 mm
(3.46 in.)
483 mm
(19.0 in.)
630 mm
(24.8 in.)
17.1 kg
(37.6 lb)
25.2 kg
(55.4 lb)
2073-700 File Module
85 mm (3.36
in.)
443 mm (17.5
in.)
698 mm (27.5
in.)
n/a 29.6 kg (65 lb)
2073-720 File Module 86 mm (3.4 in.)
445 mm (17.5
in)
764 mm (29.4
in)
n/a 30 kg (65 lb)
Additional space requirements
Ensure that these additional space requirements, as shown in Table 29, are available
around the enclosures.
Table 29. Clearances
Location Additional space requirements Reason
Left and right sides 50 mm (2 in.) Cooling air flow
Back Minimum: 100 mm (4 in.) Cable exit
Supported drives for Storwize V7000 Gen1 enclosures
Table 30 provides drive specifications for your Storwize V7000 Unified system.
Table 30. Drive specifications
Model and type 3.5-inch drives 2.5-inch drives
2076-112 Control Enclosure with 12
3.5-inch drive slots
2 TB 3.5" 7.2K RPM Nearline SAS disk -
2076-124 Control Enclosure with 24
2.5-inch drive slots
-
v 300 GB 2.5" 10K RPM SAS disk
v 450 GB 2.5" 10K RPM SAS disk
v 600 GB 2.5" 10K RPM SAS disk
v 300 GB 2.5" E-MLC
(enterprise-grade multilevel cell)
flash drive
2076-212 Expansion Enclosure with
12 3.5-inch drive slots
2 TB 3.5" 7.2K RPM Nearline SAS disk -
Chapter 2. Planning for adding file modules 31
