2 - 1
SECTION 2 INSIDE VIEW
• LOGIC UNIT
(TOP VIEW)
• LOGIC UNIT
(BOTTOM VIEW)
+5 REG
(IC6)
AF POWER AMP
(IC1071)
CI-V INTERFACE
(Q102)
INVERTER
(IC103)
+8 REG
(IC100)
+5 REG
(IC101)
LCD DRIVER
(IC7)
FRONT CPU
(IC1)
EEPROM
(IC2)
+5V REG
(IC5)
