Icom IC-7851 Servise Manual

3-2
M UNITS LOCATION
M CONNECTION
RF-B UNITRF-A UNIT
MAIN UNIT
<Bottom view>
RF-A UNIT
RF-A UNIT
MAIN UNIT
L
B
<Rear view>
<Front view>
AC millivolt meter
Speaker (8 Ω)
3.5 mm (1/8’’ ) monoral plug
+
−
+
Short plug:
(Short)
3.5 mm (1/8’’ ) monoral plug
RF-A UNIT
RF-A UNIT
MAIN UNIT
RF power meter
SSG
CAUTION !
DO NOT select an TX adjustment item while an SSG
is connected to the antenna connector.
Audio
generator
PTT
[MIC]
AC millvolt
meter
Digital multimeter
Frequency counter
100 Ω dummy load
(SWR=2)
−
