5-2
[CHASSIS PARTS]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
MP133 8810004431 PH M3 X 6 ZK3 9
MP134 8810008451 BIND M4 X 8 ZK3 2
MP135 8810009461 FLAT M3 X 8 ZK3 4
MP136 8810009461 FLAT M3 X 8 ZK3 4
MP137 8810007231 SET SCREWH M3 X 8 ZC3 4
MP138 8810009461 FLAT M3 X 8 ZK3 4
MP139 8810004431 PH M3 X 6 ZK3 8
MP140 8830000360 NUT M 5 NI 1
MP141 8850000150 FLAT WASHER M 5 NI BS 2
MP142 8810004540 BIND M3 X 8 SUS [#02] 4
8810004540 BIND M3 X 8 SUS [#03] 4
8810004540 BIND M3 X 8 SUS [#04] 4
8810004540 BIND M3 X 8 SUS [#05] 4
8810004540 BIND M3 X 8 SUS [#06] 4
8810004540 BIND M3 X 8 SUS [#07] 4
8810004540 BIND M3 X 8 SUS [#08] 4
8810011720 SCREW BiH M3X8 AU [#22] 4
8810011720 SCREW BiH M3X8 AU [#23] 4
MP143 8810011710 SCREW BiH M4X8 SUS [#02] 2
8810011710 SCREW BiH M4X8 SUS [#03] 2
8810011710 SCREW BiH M4X8 SUS [#04] 2
8810011710 SCREW BiH M4X8 SUS [#05] 2
8810011710 SCREW BiH M4X8 SUS [#06] 2
8810011710 SCREW BiH M4X8 SUS [#07] 2
8810011710 SCREW BiH M4X8 SUS [#08] 2
8810011700 SCREW BiH M4X8 AU [#22] 2
8810011700 SCREW BiH M4X8 AU [#23] 2
MP144 8850001710 SEALING WASHER (R) 6
MP201 8930091650 HIMELON SHEET (DK) 1
MP202 8930091330 3615 MAGNETIC SHIELD 2
MP203 8930090940 PA-30B 1
MP204 8930056160 DOUBLE SIDE TAPE (AG) 1
MP205** 8930076780 SPONGE (KE) 1
MP206 8930069610 SPONGE (IV) 1
MP207 8930070820 SHIELD SPONGE (BK) 1
MP208 8930006960 SPONGE (Y) 2
MP209 8930075580 SHIELD SPONGE (CH) 3
MP210 8930090300 SHIELD SPONGE (DF) 1
MP211 8930057790 SHIELD SPONGE (K) 8
MP212 8930090300 SHIELD SPONGE (DF) 2
MP213 8930091770 AL SHEET (AS) 1
MP214 8930063800 SHIELD SPONGE (AH) 2
MP215 8930076540 SHIELD SPONGE (CK) 1
MP216 8930063800 SHIELD SPONGE (AH) 2
MP217 8930082231 SHIELD SPONGE (CQ)-1 3
MP218 8930048961 SHIELD TAPE (B)-1 2
MP219 8930091910 SPONGE (NF) 1
MP220 8930091810 SPONGE (NE) 1
MP221 8930071550 SHIELD SPONGE (BM) 1
MP222 8930090940 PA-30B 1
MP223 8930090940 PA-30B 1
MP224 8930091820 SHIELD SPONGE (DH) 1
MP225 8930090940 PA-30B 1
MP226 8930091970 3615 EMI NET [#02] 1
8930091970 3615 EMI NET [#03] 1
8930091970 3615 EMI NET [#04] 1
8930091970 3615 EMI NET [#05] 1
8930091970 3615 EMI NET [#06] 1
8930091970 3615 EMI NET [#07] 1
8930091970 3615 EMI NET [#22] 1
8930091970 3615 EMI NET [#23] 1
MP227 8930091150 INSULATION SHEET (NL) 1
MP228 8930056160 DOUBLE SIDE TAPE (AG) 1
MP229 8930076430 INSULATION SHEET (MF) [#22] 2
8930076430 INSULATION SHEET (MF) [#23] 2
MP231 8930091790 SPONGE (NC) 2
MP232 8930074910 SPONGE (JZ) 4
MP233 8930039621 LEG CUSHION (A)-1 2
MP301 8950003640 CS-2 UL 2
MP302 8930072140 MR CAP (I-03631) <GA> 4
MP303 8930091610 BNC-R PROTECTION CAP <GA> 6
MP404 8930063790 SHIELD SPONGE (AI) 1
MP405 8930071220 SPONGE (JI) 1
MP412 8930088941 SHIELD SPONGE (DE)-1 3
MP421 8950003640 CS-2 UL 1
MP501* 8930091830 SHIELD SPONGE (DJ) 1
MP502 8930067290 SHIELD SPONGE (AR) 1
MP503 8930067290 SHIELD SPONGE (AR) 1
MP504 8930091790 SPONGE (NC) 2
MP551 8930059380 SHIELD SPONGE (X) 1
MP552* 8930068000 SHIELD SPONGE (AT) 1
MP553* 8930068000 SHIELD SPONGE (AT) 1
MP554* 8930059330 SHIELD SPONGE (W) 1
MP555 8930059330 SHIELD SPONGE (W) 1
MP556 8930092030 INSULATION SHEET (NR) 2
MP557* 8930017191 EARTH SPRING (F)-1 1
MP558* 8930061490 SHIELD SPONGE (AB) 1
[FRONT UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
W1** 8900016150 OPC-1679 (P0.5N30L80) 1
W2** 8900016150 OPC-1679 (P0.5N30L80) 1
W3** 8900016150 OPC-1679 (P0.5N30L80) 1
W4** 8910000400 FFC-1041 (P0.5N40L60) 1
W5** 8900017930 OPC-1336A (P1N18L70) 1
W6** 8910000380 FFC-1039 (P1.0N18L120) 1
W7** 8900021220 OPC-2264 (P0.5N14L80) 1
W8** 8900009231 OPC-908A (P1N10L60) 1
W9** 8900009231 OPC-908A (P1N10L60) 1
W10** 8900009231 OPC-908A (P1N10L60) 1
W11** 8900009231 OPC-908A (P1N10L60) 1
W12** 8900009231 OPC-908A (P1N10L60) 1
W13** 8900009231 OPC-908A (P1N10L60) 1
W14** 8900009231 OPC-908A (P1N10L60) 1
W15** 8900009231 OPC-908A (P1N10L60) 1
W16** 8900009231 OPC-908A (P1N10L60) 1
W17** 8910000370 FFC-1038 (P0.5N40L240) 1
EP1 6910023970
T070W2D6
<PVD>
1
EP11 6910020500 RMS20-250-201-1B (-1P/E) 1
EP12 6910020500 RMS20-250-201-1B (-1P/E) 1
EP13 0880001460 EX-2500 [#03] SENSOR 1
EP101 6910022560 SNAP PLATE 1
EP102 6910022560 SNAP PLATE 1
MP1 8010023280 3615 SUB CHASSIS 1
MP2 8210030210 3615 FRONT PANEL (A) [#02] 1
8210030210 3615 FRONT PANEL (A) [#03] 1
8210030210 3615 FRONT PANEL (A) [#04] 1
8210030210 3615 FRONT PANEL (A) [#05] 1
8210030210 3615 FRONT PANEL (A) [#06] 1
8210030210 3615 FRONT PANEL (A) [#07] 1
8210030210 3615 FRONT PANEL (A) [#08] 1
8210030200 3615 FRONT PANEL [#22] 1
8210030200 3615 FRONT PANEL [#23] 1
MP3 8210030890 2590 10KEY(C)SET (KNOB 4) [#02] 1
8210030890 2590 10KEY(C)SET (KNOB 4) [#03] 1
8210030890 2590 10KEY(C)SET (KNOB 4) [#04] 1
8210030890 2590 10KEY(C)SET (KNOB 4) [#05] 1
8210030890 2590 10KEY(C)SET (KNOB 4) [#06] 1
8210030890 2590 10KEY(C)SET (KNOB 4) [#07] 1
8210030890 2590 10KEY(C)SET (KNOB 4) [#08] 1
8210030900 2590 10KEY(B)SET (KNOB 4) [#22] 1
8210030900 2590 10KEY(B)SET (KNOB 4) [#23] 1
MP8 8930060640 2590 CF LENS 2
MP10 8610015520 KNOB K231 (C)-1 ASSEMBLY [#02] 1
8610015520 KNOB K231 (C)-1 ASSEMBLY [#03] 1
8610015520 KNOB K231 (C)-1 ASSEMBLY [#04] 1
8610015520 KNOB K231 (C)-1 ASSEMBLY [#05] 1
8610015520 KNOB K231 (C)-1 ASSEMBLY [#06] 1
8610015520 KNOB K231 (C)-1 ASSEMBLY [#07] 1
8610015520 KNOB K231 (C)-1 ASSEMBLY [#08] 1
8610015490 KNOB K231 (B)-1 ASSEMBLY [#22] 1
8610015490 KNOB K231 (B)-1 ASSEMBLY [#23] 1
MP11 8610015580 KNOB K232 (C)-1 ASSEMBLY [#02] 2
8610015580 KNOB K232 (C)-1 ASSEMBLY [#03] 2
8610015580 KNOB K232 (C)-1 ASSEMBLY [#04] 2
8610015580 KNOB K232 (C)-1 ASSEMBLY [#05] 2
8610015580 KNOB K232 (C)-1 ASSEMBLY [#06] 2
8610015580 KNOB K232 (C)-1 ASSEMBLY [#07] 2
8610015580 KNOB K232 (C)-1 ASSEMBLY [#08] 2
8610015500 KNOB K232 (B)-1 ASSEMBLY [#22] 2
8610015500 KNOB K232 (B)-1 ASSEMBLY [#23] 2
MP12 8610015510 KNOB K230 (C)-2 ASSEMBLY [#02] 1
8610015510 KNOB K230 (C)-2 ASSEMBLY [#03] 1
8610015510 KNOB K230 (C)-2 ASSEMBLY [#04] 1
8610015510 KNOB K230 (C)-2 ASSEMBLY [#05] 1
8610015510 KNOB K230 (C)-2 ASSEMBLY [#06] 1
8610015510 KNOB K230 (C)-2 ASSEMBLY [#07] 1
8610015510 KNOB K230 (C)-2 ASSEMBLY [#08] 1
8610015480 KNOB K230 (B)-2 ASSEMBLY [#22] 1
8610015480 KNOB K230 (B)-2 ASSEMBLY [#23] 1
MP13 8610014811 KNOB K233 (C)-1 [#02] 1
8610014811 KNOB K233 (C)-1 [#03] 1
8610014811 KNOB K233 (C)-1 [#04] 1
8610014811 KNOB K233 (C)-1 [#05] 1
8610014811 KNOB K233 (C)-1 [#06] 1
8610014811 KNOB K233 (C)-1 [#07] 1
8610014811 KNOB K233 (C)-1 [#08] 1
8610014801 KNOB K233 (B)-1 [#22] 1
8610014801 KNOB K233 (B)-1 [#23] 1
MP14 8610014911 KNOB K236 (C)-1 [#02] 1
8610014911 KNOB K236 (C)-1 [#03] 1
8610014911 KNOB K236 (C)-1 [#04] 1
8610014911 KNOB K236 (C)-1 [#05] 1
8610014911 KNOB K236 (C)-1 [#06] 1
8610014911 KNOB K236 (C)-1 [#07] 1
8610014911 KNOB K236 (C)-1 [#08] 1
8610014901 KNOB K236 (B)-1 [#22] 1
8610014901 KNOB K236 (B)-1 [#23] 1
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
To Next Page
