5-1

[CHASSIS PARTS] [CHASSIS PARTS]

REF ORDER

DESCRIPTION

QTY.

NO. NO.

REF ORDER

DESCRIPTION

QTY.

NO. NO.

W1** 8900016290 OPC-1706 1

W3** 8970025620 1.5D 150MM (SX3615 CH 6G3) 1

W5** 8970025590 1.5D 130MM (SX3615 CH 6G4) 1

W7** 8970025600 1.5D 110MM (SX3615 CH 6G2) 1

W9** 8970025211 1.5DCOAXIAL250MM-1 C31/C31 1

W11** 8970024982 1.5DCOAXIAL200MM-2 C31/C31 1

W13** 8970024202 1.5DCOAXIAL300MM-2 C31/C31 1

W15** 8970025630 1.5D 420MM (SX3615 CH 6G5) 1

W17** 8970025640 1.5D 570MM (SX3615 CH 6G6) 1

W19** 8970024083 1.5DCOAXIAL180MM-3 C31/C31 1

W21** 8970024762 1.5DCOAXIAL130MM-2 C31/C31 1

W23** 8970025610 1.5DCOAXIAL1100MM C31/C31 1

W25** 8970024232 1.5DCOAXIAL390MM-2 (F/I)C31/C31 1

W27** 8970024202 1.5DCOAXIAL300MM-2 C31/C31 1

W29** 8970025211 1.5DCOAXIAL250MM-1 C31/C31 1

W31** 8970024202 1.5DCOAXIAL300MM-2 C31/C31 1

W33** 8970025211 1.5DCOAXIAL250MM-1 C31/C31 1

W35** 8970024202 1.5DCOAXIAL300MM-2 C31/C31 1

W37** 8970024461 1.5DCOAXIAL570MM-1 (J) C31/C31 1

W39** 8970024992 1.5DCOAXIAL650MM-2 C31/C31 1

W41** 8970024461 1.5DCOAXIAL570MM-1 (J) C31/C31 1

W43** 8970024412 1.5DCOAXIAL330MM-2 (T) C31/C31 1

W45** 8970024202 1.5DCOAXIAL300MM-2 C31/C31 1

W47** 8970024442 1.5DCOAXIAL510MM-2 (B) C31/C31 1

W49** 8970024202 1.5DCOAXIAL300MM-2 C31/C31 1

W51** 8970024232 1.5DCOAXIAL390MM-2 (F/I)C31/C31 1

W61** 8900013032 OPC-1346R-1 1

W62** 8900013042 OPC-1347R-1 1

W63** 8900013052 OPC-1348R-1 1

W81** 8910000390 FFC-1040 (P0.5N30L150) 1

W82** 8910000360 FFC-1034 (P1.0N12L50) 1

W83** 8900016150 OPC-1679 (P0.5N30L80) 1

W84** 8900018010 OPC-994A (P0.5N30L220) 1

W85** 8910000390 FFC-1040 (P0.5N30L150) 1

W86** 8900009231 OPC-908A (P1N10L60) 1

W87** 8910000410 FFC-1043 (P1.0N10L190) 1

W88** 8910000350 FFC-1033 (P0.5N30L270) 1

W89** 8910000350 FFC-1033 (P0.5N30L270) 1

W90** 8900018010 OPC-994A (P0.5N30L220) 1

W91** 8900018010 OPC-994A (P0.5N30L220) 1

W92** 8910000440 FFC-1047 (P0.5N40L120) 1

W93** 8900016150 OPC-1679 (P0.5N30L80) 1

W94** 8900017510 OPC-1851 (P1N24L380) 1

W95** 8900017090 OPC-1826 (P1N10L120) 1

W96** 8910000430 FFC-1046 (P0.5N50L190) 1

W97** 8910000420 FFC-1044 (P0.5N20L190) 1

W101 8900021920 OPC-2351 <SSC> 1

W102 8900021920 OPC-2351 <SSC> 1

W103 8900021920 OPC-2351 <SSC> 1

W104 8900021920 OPC-2351 <SSC> 1

W105 8900021920 OPC-2351 <SSC> 1

W106 8900021920 OPC-2351 <SSC> 1

W111** 8920001190 CAB-1153 (SX3615 NO.1) 1

W121** 8600037470 SX3615 P121*P122CH (6G1) NO.2 1

W131** 8600037480 SX3615 P131*P132CH NO.3 1

W141** 8600037490 SX3615 P141*P142CH NO.4 1

W151** 8600037500 SX3615 P151*P152CH NO.5 1

W161** 8600037510 SX3615 P161*P162*P163CH NO.6 1

W171** 8600037520 SX3615 P171*P172CH NO.7 1

W181** 8600037530 SX3615 P181*P182*P183CH NO.8 1

W191** 8600037540 SX3615 P191*P192CH NO.9 1

W211** 8920001310 CAB-1168 <GBE> 1

W221** 8600037570 SX3615 P221*P222CH NO.12 1

W231** 8600037580 SX3615 P231*P232CH NO.13 1

W241** 8600037060 SX2590 P119*P120CH 1

W251** 8900013060 OPC-1349 1

SP1 2510001390 2844 SP BOX 1

MF1 2710000520 SB0812H-ICOM-00 1

EP1 6910016052 FP2212B-2 FCC ROHS [#02] 1

6910016062 FP2212C-2 RTTE ROHS [#03] 1

6910016062 FP2212C-2 RTTE ROHS [#04] 1

6910016062 FP2212C-2 RTTE ROHS [#05] 1

6910016062 FP2212C-2 RTTE ROHS [#06] 1

6910016062 FP2212C-2 RTTE ROHS [#07] 1

6910016062 FP2212C-2 RTTE ROHS [#08] 1

6910016052 FP2212B-2 FCC ROHS [#22] 1

6910016062 FP2212C-2 RTTE ROHS [#23] 1

EP2 6910011941 ZCAT2436-1330A-BK 1

EP7 6910011941 ZCAT2436-1330A-BK 1

EP8 6910011960 ZCAT1518-0730 1

MP1 8010023200 3615 CHASSIS 1

MP2 8210030220 3615 REAR PANEL 1

MP3 8210030301 2590 SIDE PANEL (B)-1 [#02] 2

8210030301 2590 SIDE PANEL (B)-1 [#03] 2

8210030301 2590 SIDE PANEL (B)-1 [#04] 2

8210030301 2590 SIDE PANEL (B)-1 [#05] 2

8210030301 2590 SIDE PANEL (B)-1 [#06] 2

8210030301 2590 SIDE PANEL (B)-1 [#07] 2

8210030301 2590 SIDE PANEL (B)-1 [#08] 2

8210030291 2590 SIDE PANEL (A)-1 [#22] 2

8210030291 2590 SIDE PANEL (A)-1 [#23] 2

MP4 8110010701 3615 L-COVER (A)-1 [#02] 1

8110010701 3615 L-COVER (A)-1 [#03] 1

8110010701 3615 L-COVER (A)-1 [#04] 1

8110010701 3615 L-COVER (A)-1 [#05] 1

8110010701 3615 L-COVER (A)-1 [#06] 1

8110010701 3615 L-COVER (A)-1 [#07] 1

8110010701 3615 L-COVER (A)-1 [#08] 1

8110010691 3615 L-COVER-1 [#22] 1

8110010691 3615 L-COVER-1 [#23] 1

MP5 8110010711 3615 U-COVER-1 [#02] 1

8110010711 3615 U-COVER-1 [#03] 1

8110010711 3615 U-COVER-1 [#04] 1

8110010711 3615 U-COVER-1 [#05] 1

8110010711 3615 U-COVER-1 [#06] 1

8110010711 3615 U-COVER-1 [#07] 1

8110010711 3615 U-COVER-1 [#08] 1

8110010681 3615 UA-COVER-1 [#22] 1

8110010681 3615 UA-COVER-1 [#23] 1

MP6 8510021350 3615 LOGIC COVER 1

MP7 8510021380 3615 SCOPE COVER Y2190 1

MP8 8510021360 3615 RF COVER 1

MP9 8510021390 3615 OSC COVER Y2188 1

MP10 8510021400 3615 LOCAL COVER 1

MP11 8510021340 3615 LOGIC CASE 1

MP12 8510021370 3615 SCOPE CASE Y2189 1

MP13 8510015851 2590 FILTER CASE-1 1

MP14 8930074921 3009 A-SP ANGLE-1 Y1075A 1

MP15 8930061281 2590 ANT ANGLE-1 1

MP16 8930090900 3615 CHA-PLATE Y2187 1

MP18 8310085770 3615 SERIAL PLATE M150X2 [#22] 1

8310085770 3615 SERIAL PLATE M150X2 [#23] 1

MP19 8930073900 3009 SPACER 3

MP20 8930011680 RUBBER LEG (G) 2

MP21 8930091360 2590 MAIN STAND (B) ASSEMBLY [#02] 2

8930091360 2590 MAIN STAND (B) ASSEMBLY [#03] 2

8930091360 2590 MAIN STAND (B) ASSEMBLY [#04] 2

8930091360 2590 MAIN STAND (B) ASSEMBLY [#05] 2

8930091360 2590 MAIN STAND (B) ASSEMBLY [#06] 2

8930091360 2590 MAIN STAND (B) ASSEMBLY [#07] 2

8930091360 2590 MAIN STAND (B) ASSEMBLY [#08] 2

8930091350 2590 MAIN STAND (A) ASSEMBLY [#22] 2

8930091350 2590 MAIN STAND (A) ASSEMBLY [#23] 2

MP23 8930090880 3615 A-NET 1

MP24 8930090890 3615 B-NET 3

MP29 8930075530 2590 RUBBER (A) (TOT)S 3

MP30* 8930035230 1546 TR-A CLIP 2

MP31 8930091200 71781-0001 2

MP101 8810008661 PHBT M3 X 8 NI-ZC3 5

MP102 8810008661 PHBT M3 X 8 NI-ZC3 17

MP103 8810008661 PHBT M3 X 8 NI-ZC3 19

MP104 8810008661 PHBT M3 X 8 NI-ZC3 7

MP105 8810008661 PHBT M3 X 8 NI-ZC3 7

MP106 8820001760 TAPPING SCREW WH B0 3X8 NI-ZC3 (BT) 12

MP107 8820001760 TAPPING SCREW WH B0 3X8 NI-ZC3 (BT) 12

MP108 8810008661 PHBT M3 X 8 NI-ZC3 18

MP109 8810008661 PHBT M3 X 8 NI-ZC3 8

MP110 8810008661 PHBT M3 X 8 NI-ZC3 8

MP111 8810008661 PHBT M3 X 8 NI-ZC3 4

MP112 8810008661 PHBT M3 X 8 NI-ZC3 9

MP113 8810008661 PHBT M3 X 8 NI-ZC3 5

MP114 8810008661 PHBT M3 X 8 NI-ZC3 2

MP115 8810008661 PHBT M3 X 8 NI-ZC3 4

MP116 8810008661 PHBT M3 X 8 NI-ZC3 4

MP117 8810008661 PHBT M3 X 8 NI-ZC3 4

MP118 8810008661 PHBT M3 X 8 NI-ZC3 4

MP119 8810009991 PHBT M3 X 8 NI-ZK3 2

MP120 8810008661 PHBT M3 X 8 NI-ZC3 2

MP121 8810008631 PHBT M3 X 6 NI-ZC3 8

MP122 8810008661 PHBT M3 X 8 NI-ZC3 4

MP123 8810008631 PHBT M3 X 6 NI-ZC3 11

MP124 8810009311 FLAT BT M3 X 6 NI-ZC3 11

MP125 8810009391 PHBT M3 X18 NI-ZC3 3

MP126 8810009991 PHBT M3 X 8 NI-ZK3 1

MP127 8810008661 PHBT M3 X 8 NI-ZC3 2

MP128 8810000391 PH M4 X12 ZC3 2

MP129 8810008451 BIND M4 X 8 ZK3 8

MP131 8810008451 BIND M4 X 8 ZK3 13

MP132 8810008451 BIND M4 X 8 ZK3 14

SECTION 5

MECHANICAL PARTS

*: Refer to “BOARD LAYOUTS” for the location.

**: Refer to “GENERAL WIRING” for the connection

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
