Icom IC-A14 Service Manual

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
5 - 1
SECTION 5 MECHANICAL PARTS
[CHASSIS PARTS]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1 6510026010 BNC-R170 1
J2 6910015860 IMSA-6277S-O2A-G 1
SP1 2510001360 K036NAX040A00-55 1
W1 8900009640 OPC-963 1
MP1 8010020410 2927 CHASSIS 1
MP2 8210024590 2927 S-FRONT PANEL (B)
(Incl. MP3, 4, 5, 6, 9, 10, 12) [IC-A14S] 1
8210024580 2927 T-FRONT PANEL (B)
(Incl. MP3, 4, 5, 6, 9, 10, 12) [IC-A14] 1
MP3 8210022790 2927 PTT PANEL 1
MP4 8930069520 2927 PTT BUTTON 1
MP5 8930074420 3074 PTT RUBBER 1
MP6 8930073610 SP NET (D) 1
MP8 8210020550 2721 REAR PANEL 1
MP9 8310070990 2927 WINDOW PLATE (B) 1
MP10 8930069510 2927 WINDOW SHEET 1
MP12 8930074360 2927 4-KEY (D) [IC-A14S] 1
8930074370 2927 KEYBOARD (A) [IC-A14] 1
MP13 8930070100 2927 MAIN SEAL (A) 1
MP14 8930063060 2721 T-RUBBER 1
MP16 8930069460 2927 SIDE PLATE 1
MP17 8930069470 2927 TOP PLATE 1
MP20 8930061880 2721 MIC SPONGE 1
MP21 8930059360 2600 RELEASE BUTTON 1
MP22 8930070362 2775 RELEASE PLATE (A)-2 1
MP23 8610007510 KNOB SPRING NO.7800 1
MP24 8610012970 KNOB N-350 (Incl. MP23) 1
MP25 8830003040 3017 ANT NUT 1
MP26 8810009561 SCREW BT B0 2X6 NI-ZK3 (BT) 2
MP27 8810009221 SCREW BT B0 2X8 NI-ZK3 (BT) 2
MP28 8810008641 0Tap 1Flat washer B0 2X4 NI-ZC3 (BT) 11
MP31 8810010430 SCREW TRUSS M3X5 SUS SSBC 1
MP32 8310066810 2927 OPTION PLATE 1
MP33 8930046020 1123 SHEET (A)-1 1
MP34 8930056540 PUSH SPRING (AH) 2
MP35 8830001701 VR NUT (Q)-1 1
MP36 8930048870 2056 A-SPONGE 1
MP37 8930070010 2893 VOL RUBBER 1
MP42 8210022780 2927 JACK PANEL 1
MP43 8810004861 SCREW PH M2X6 ZK3 2
[MAIN UNIT]
[ACCESSORIES]
[PA UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J2* 6450000131 HSJ1102-018540 1
J3* 6510016381 52465-1071 1
J4* 6510021901 BM02B-ASRS-TF (LF) (SN) 1
J5* 6450002250 HSJ1456-010320 1
DS1 5030003070 S11313 1
MC1 7700002760 EM6027P-46C33-G-01 1
S23 2260002840 SKHLLFA010 1
S24* 2230001060 EVQ-PUL 02K 1
S25* 2260002800 SW-167 (SKQT) 1
S26* 2260002800 SW-167 (SKQT) 1
S27* 2260002800 SW-167 (SKQT) 1
EP20 8930063020 SRCN-2721-SP-N-W 2
MP3* 8510016130 2721 VCO CASE 1
MP4 8510016120 2721 VCO COVER 1
MP5 8930069480 2927 LCD HOLDER 1
MP6 8210020570 2721 REFLECTOR 1
MP7 8930070080 WHITE SHEET (V) 1
MP8 8510017720 2927 MAIN SHIELD 1
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6910017680 9230B-1-04Z140-PT1 1
J2* 6910017680 9230B-1-04Z140-PT1 1
J3* 6910017680 9230B-1-04Z140-PT1 1
MP1* 8410002531 2681 PA HEATSINK-1 1
MP2* 8510018750 3074 PA SHIELD PLATE 1
[ANT UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
MP1* 8510017640 2927 ANT PLATE 1
REF ORDER
DESCRIPTION QTY.
NO. NO.
EP1 3310002130 FA-B02AR 1
EP2 (Optional) BP-232N [IC-A14] only 1
EP3 (Optional) BC-179 [IC-A14]only 1
EP4 (Optional) BC-174A [USA] only 1
(Optional) BC-174E [EXP] only 1
EP5 (Optional) BP-261 except [USA-01], [EXP-01] 1
EP6 6910018620 BLACK HANDY STRAP 1
MP1 (Optional) MB-94 1
*: Refer to SECTION 7 “BOARD LAYOUTS.”
[DC UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1 6910015881 9230B-1-02Z141-PT1 1
