Icom IC-A15S User Manual

34
12
OPTIONAL HEADSET CONNECTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
D OPC-499 (HEADSET ADAPTER) connection
When using a headset (3rd party products) via the OPC-499 HEADSET ADAPTER, the transceiver outputs your transmitted voice
to the headset for monitoring. See “n Side tone function” (p. 11) when setting the side tone level.
PTT
OPC-499
Transceiver
PTT switch
HEADSET
(Must be purchased
separately)
Use a PTT switch with a
3.5 mm (
1
⁄ 8 ˝) diameter
plug, if required.
NOTICE!
Some headsets do not work properly when used with the
IC-A15/S.
Therefore, ask your dealer for details about headsets
compatible for operation with the IC-A15/S with the head-
set.
