BATTERY CHARGING
Battery chargers (continued) ■
D Using the BC-197 to rapid charge the BP-264 or
BP-265
The BC-197 rapidly charges up to six battery packs.
ChargingtimefortheBP-264:Approximately2hours
ChargingtimefortheBP-265:Approximately2.5hours
Thefollowingadditionalitemisrequired:
•AnACadapter(notsuppliedwithsomeversions)ortheOPC-656d c
p o w e r c a b l e
(An AC adapter is
not supplied with
some versions.)
AC adapter
(Connect to a DC power supply;
12 to 16 V/at least 7 A)
Red line : + Black line : _
Transceiver
Battery pack
Tu rn OFF the power
Status indicator
(each indicator independently functions)
OPC-656 (DC power cable)
The charger adapters are in-
stalled in each slot. The shape
of charger adapter depends
on the version of the BC-197.
