6 - 4
ADJUSTMENT
TRANSCEIVER’S
CONDITION
OPERATION
ADJUSTMENT
ITEM
VALUE
PLL LOCK
VOLTAGE
(RX)
1 • Channel : 1-1
• Receiving
1) Connect an RF power meter to the
antenna connector.
2) Set the adjustment value on the "Adjust
Utility" screen.
[RX LVA(Adjust)] 1.1 V
(TX) 2 • Channel : 1-2
• Transmitting
[TX LVA(Adjust)]
(RX) 3 • Channel : 1-3
• Receiving
Click the [Update (F5)] button to check on
the "I/O Check window" as below.
[LVIN]
(On the "I/O
Check window")
3.0–4.0 V
(Verify)
(TX) 4 • Channel : 1-4
• Transmitting
2.5–3.5 V
(Verify)
REFERENCE
FREQUENCY
1 • Channel : 1-5
• Transmitting
Loosely couple a frequency counter to the
antenna connector. [REF]
174.000000
MHz
(±250 Hz)
6-2 FREQUENCY ADJUSTMENTS
1) Select an adjustment item using [
]/[
] on the PC's keyboard.
2) Set or modify the adjustment value as specifi ed using [
]/[
] on the PC's keyboard, then push [ENTER].
• I/O Check screen
(The values shown above are exsample only.
Each transceiver has own values.)
Lock voltage
appears here
* * *
