Icom iC-FR5000 Service Manual

6-3 TRANSMIT ADJUSTMENT (continued)
1) Select an adjustment item using cursor or [
↑
] / [
↓
] keys of the PC’s keyboard.
2) Set or modify the adjustment value as specifi ed using [
←
] / [
→
] keys of the PC’s keyboard, then push the [ENTER] key.
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
ADJUSTMENT
ITEM
VALUE
ANALOG
DEVIATION
-Preparation-
1 – • Set the item [TX Mode] to "1." [TX Mode] "1"
2• Connect a Modulation Analyzer
to the TX antenna connector
through an attenuator.
• Set the Modulation Analyzer as;
HPF : OFF
LPF : 20 kHz
De-emphasis : OFF
Detector : (P-P)/2
––
3• Connect an Audio Generator
to the MIC line through the JIG
cable.
• Set the Audio Generator as;
Modulation : 1050 Hz
Level : 40 mVrms
Waveform : Sine wave
––
-Adjust-
(Wide)
4 • CH. : 1-23
• Transmitting
1) Adjust the deviation using [
←
] / [
→
]
keys of the PC’s keyboard.
2) Push the [ENTER] key to store the
adjust value.
[MOD (Wide)]
±4.05–4.15
kHz
(Middle)
<[FR5100] only>
5 • CH. : 1-24
• [Wide Band Width]
: "Middle" (see the page 6-4)
• Transmitting
[MOD (Middle)]
±3.15–3.25
kHz
(Narrow) 6 • CH. : 1-25
• Transmitting
[MOD (Narrow)]
±2.05–2.15
kHz
CTCSS/DTCS
DEVIATION
-Preparation-
1
–
• Set the item [TX Mode] to "3."
[TX Mode]
"3"
-Adjust- 2 • CH. : 1-26
• Transmitting
1) Adjust the deviation using [
←
] / [
→
]
keys of the PC’s keyboard.
2) Push the [ENTER] key to store the
adjust value.
[CTCSS]
±0.68–0.72
kHz
6-4 RECEIVE ADJUSTMENT
1) Select an adjustment item using cursor or [
↑
] / [
↓
] keys of the PC’s keyboard.
2) Set or modify the adjustment value as specifi ed using [
←
] / [
→
] keys of the PC’s keyboard, then push the [ENTER] key.
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
ADJUSTMENT
ITEM/POINT
VALUE
RECEIVE
SENSITIVITY
-Preparation-
1 – • Set the item [RX Mode] to "1." [RX Mode] "1"
2• Connect an SSG to the RX
antenna connector.
• Set the SSG as;
Level : +20 dB
μ
Modulation : 1 kHz
Deviation : 3.5 kHz
––
-Adjust-
(Band center)
3 • CH. : 1-27
• Receiving
1) Set the SSG as;
Frequency : 136.100 MHz
2) Select the item [BPF C ALL], then
push the [ENTER] key.
[BPF C ALL]
(Automatic
adjustment)
(Band high)
<[FR5000] only>
4 • CH. : 1-28
• Receiving
1) Set the SSG as;
Frequency : 173.900 MHz
2) Select the item [BPF H ALL], then
push the [ENTER] key.
[BPF H ALL]
6 - 8
