Icom iC-FR5000 Service Manual

7 - 1
SECTION 7 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC500 1130009121 S.IC S1D15206F00A200 B 69.4/35.9
IC501 1110005771 S.IC S-80942CNMC-G9CT2G B 105.3/24
IC502 1140014580 S.IC uPD78F1153GK-GAK-AX B 101.3/38.7
IC503 1110005350 S.IC NJM2870F05-TE1-#FZZB B 47.2/30.5
IC506 1140013200 S.IC CD4053BPWR B 39.1/31.7
IC508 1110002751 S.IC TA75S01F (TE85R,F) B 143/18
IC509 1110006770 S.IC TDA8547TS/N B 28.4/55.8
Q500 1590001050 S.TR DTC114TUA T106 B 148.4/41.4
Q501 1590001050 S.TR DTC114TUA T106 B 161.8/34.6
Q502 1590001050 S.TR DTC114TUA T106 B 161.8/41.4
Q503 1590001050 S.TR DTC114TUA T106 B 148.4/34.6
Q504 1590001050 S.TR DTC114TUA T106 B 91.4/45.6
Q506 1590001190 S.TR XP6501-(TX) .AB B 32.9/48.1
Q508 1520000460 S.TR 2SB1132 T100 R B 36.9/52.6
Q510 1590001050 S.TR DTC114TUA T106 B 152.8/53.2
Q511 1590001050 S.TR DTC114TUA T106 B 166.2/53
Q513 1590001060 S.TR DTA114TUA T106 B 168.7/53
Q514 1590001060 S.TR DTA114TUA T106 B 160.1/49.6
Q515 1590001060 S.TR DTA114TUA T106 B 155.3/53.2
Q516 1590001060 S.TR DTA114TUA T106 B 145.3/49.9
Q517 1590001050 S.TR DTC114TUA T106 B 160.1/46.9
Q518 1590001050 S.TR DTC114TUA T106 B 145.3/47
D503 1790001260 S.DIO MA2S077-(TX) B 112.3/33.9
D504 1790001250 S.DIO MA2S111-(TX) B 95/45.8
D505 1790001450 S.DIO RB160L-40 TE-25 B 41.8/26.6
D506 1790001450 S.DIO RB160L-40 TE-25 B 63.2/6.6
D507 1790000950 S.ZEN MA8056-M (TX) B 160.8/29.9
D508 1750000370 S.DIO DA221 TL B 153.2/27.7
D509 1750000370 S.DIO DA221 TL B 166.4/28.1
D510 1790001250 S.DIO MA2S111-(TX) B 43.2/51.5
D511 1790001250 S.DIO MA2S111-(TX) B 115.8/44.9
D512 1790001250 S.DIO MA2S111-(TX) B 65.3/10.2
D513 1790001250 S.DIO MA2S111-(TX) B 36.3/24.4
X501 6050012680 S.XTL CR-858 (SMD-49/18.432MHZ) B 113.1/28.2
L500 6200002861 S.COL NLV25T-4R7J B 106/17.9
L501 6200003640 S.COL MLF1608E 100K-T B 161.5/17.9
L502 6200002861 S.COL NLV25T-4R7J B 85.9/39.3
R500 7030003810 S.RES ERJ3GEYJ 125 V (1.2 M) B 83.5/43.7
R501 7030003810 S.RES ERJ3GEYJ 125 V (1.2 M) B 87.4/47.5
R506 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 157.7/36.3
R507 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) B 167.9/44.3
R508 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 167.9/37.7
R509 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) B 155.4/44.5
R510 7030005530 S.RES ERJ2GEJ 100 X (10) B 106.8/30.5
R511 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 105.8/30.5
R512 7510001730 S.TMR ERTJOEP 473J B 103.1/48.9
R513 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 102.2/49.8
R514 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 113.1/32.2
R515 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 112.3/35.9
R516 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 103.2/26.4
R517 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 110.3/33
R518 7410001140 S.ARY EXB28V104JX B 106.9/47.1
R519 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 105.4/48.4
R520 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 96.1/30.7
R523 7030005710 S.RES ERJ2GEJ 121 X (120) B 114.1/37.6
R524 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 104.4/48.4
R525 7030005710 S.RES ERJ2GEJ 121 X (120) B 113.2/37.6
R526 7030005710 S.RES ERJ2GEJ 121 X (120) B 112.3/37.6
R532 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 33.2/45.5
R533 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) B 31.2/47.7
R534 7030008290 S.RES ERJ2GEJ 183 X (18 k) B 32.2/45.7
R536 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 158.7/30.8
R538 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 155.7/29.3
R539 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 27.6/51.1
R540 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 26.6/49.9
R541 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 139.1/31.9
R542 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 26.1/51.1
R543 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 137.3/31.5
R544 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 164.9/29.3
R545 7030004980 S.RES ERJ2GEJ 101 X (100) B 140.3/19.9
R546 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 164.8/27.7
R547 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 155.7/27.7
R548 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 159.8/28
R549 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 32/51.3
R551 7210003050 VAR EVU-F2KFK3 B14 (10KB)
R552 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 142.3/20.3
R553 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 144.6/20.1
R554 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 32.6/53.4
R556 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 161.1/19
R557 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 29.2/51.3
R558 7030008370 S.RES ERJ2GEJ 561 X (560) B 169.1/51.1
R559 7030008370 S.RES ERJ2GEJ 561 X (560) B 155.7/51
R560 7030010040 S.RES ERJ2GEJ-JPW B 139.4/17.1
R562 7030003720 S.RES ERJ3GEYJ 224 V (220 k) B 86.2/43.7
R563 7030003720 S.RES ERJ3GEYJ 224 V (220 k) B 88.2/44.9
R564 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) B 153/19.8
R566 7030008370 S.RES ERJ2GEJ 561 X (560) B 161.9/49.1
R567 7030008370 S.RES ERJ2GEJ 561 X (560) B 148.3/49.9
S.=Surface mount
[FRONT UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R568 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 87.4/16.9
R570 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 103/24.8
R571 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 45.8/51.5
R572 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 46.2/50.3
R573 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 108.3/33
R574 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 108.3/32.1
R575 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 34.7/24.6
R576 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 62.6/12.8
C500 4030016930 S.CER ECJ0EB1A104K B 79.3/47.9
C501 4030016930 S.CER ECJ0EB1A104K B 80.8/47.4
C502 4030016930 S.CER ECJ0EB1A104K B 80.8/46.5
C503 4030016930 S.CER ECJ0EB1A104K B 80.4/45.3
C504 4030016930 S.CER ECJ0EB1A104K B 81.3/45.3
C505 4030017490 S.CER C1608 JB 1A 105K-T B 80.9/41
C506 4030017460 S.CER ECJ0EB1E102K B 83.9/39.8
C507 4030017490 S.CER C1608 JB 1A 105K-T B 80.9/39.5
C508 4030017730 S.CER ECJ0EB1E471K B 146.4/41.2
C509 4030017730 S.CER ECJ0EB1E471K B 159.8/34.4
C510 4030017730 S.CER ECJ0EB1E471K B 159.9/41.2
C511 4030017730 S.CER ECJ0EB1E471K B 146.4/34.4
C512 4030017030 S.CER ECJ0EB1A273K B 104.7/21.7
C513 4030017630 S.CER ECJ0EC1H120J B 106.4/29.3
C514 4030017420 S.CER ECJ0EC1H470J B 157.7/44.5
C515 4030016790 S.CER ECJ0EB1C103K B 103.5/50.2
C516 4030017580 S.CER ECJ0EC1H060C B 113.1/31.3
C517 4030016930 S.CER ECJ0EB1A104K B 102.2/50.7
C518 4030016790 S.CER ECJ0EB1C103K B 113.3/35.1
C519 4030017640 S.CER ECJ0EC1H150J B 111.3/31.8
C520 4030016930 S.CER ECJ0EB1A104K B 105.1/27.1
C521 4030018900 S.CER ECJ0EB0J474K B 104.9/30
C522 4550006480 S.TAN TEESVA 1C 475M8R B 46.7/33.2
C523 4030017330 S.CER ECJ0EF1C104Z B 44.9/31
C524 4030016790 S.CER ECJ0EB1C103K B 49.9/29.5
C525 4550006250 S.TAN TEESVA 1A 106M8R B 49/27.7
C526 4030016930 S.CER ECJ0EB1A104K B 48.9/26.1
C527 4030016930 S.CER ECJ0EB1A104K B 34.3/30
C530 4030017460 S.CER ECJ0EB1E102K B 34.5/55.4
C531 4550006250 S.TAN TEESVA 1A 106M8R B 106.6/20.2
C532 4030017460 S.CER ECJ0EB1E102K B 31.3/45.7
C533 4030017460 S.CER ECJ0EB1E102K B 45.3/27
C534 4030016930 S.CER ECJ0EB1A104K B 62.1/14.2
C535 4030016930 S.CER ECJ0EB1A104K B 30.7/49
C536 4030017460 S.CER ECJ0EB1E102K B 161/28.5
C537 4030017460 S.CER ECJ0EB1E102K B 33.6/53.4
C538 4030018860 S.CER ECJ0EB0J105K B 26.6/49
C539 4030017420 S.CER ECJ0EC1H470J B 154.8/27.7
C540 4510008590 S.ELE EEE1AA101SP B 36.9/59.4
C541 4030017330 S.CER ECJ0EF1C104Z B 150.1/20
C542 4030017460 S.CER ECJ0EB1E102K B 139.3/19.9
C544 4550006250 S.TAN TEESVA 1A 106M8R B 29.7/60.8
C545 4030017420 S.CER ECJ0EC1H470J B 168.1/28.1
C546 4030017420 S.CER ECJ0EC1H470J B 137.3/32.4
C547 4030017420 S.CER ECJ0EC1H470J B 134.2/32.4
C548 4030017460 S.CER ECJ0EB1E102K B 161/27.5
C549 4030017460 S.CER ECJ0EB1E102K B 44.1/47.4
C551 4030017420 S.CER ECJ0EC1H470J B 158.1/19.3
C553 4030017420 S.CER ECJ0EC1H470J B 140.6/17.6
C555 4030018860 S.CER ECJ0EB0J105K B 148.5/17.9
C556 4030016790 S.CER ECJ0EB1C103K B 143.1/23.6
C558 4550006480 S.TAN TEESVA 1C 475M8R B 143.5/22
C559 4030017730 S.CER ECJ0EB1E471K B 166.3/51.1
C560 4030017730 S.CER ECJ0EB1E471K B 153.1/51.1
C561 4030017730 S.CER ECJ0EB1E471K B 161.9/46.9
C562 4030017730 S.CER ECJ0EB1E471K B 147.4/46.6
C563 4030016930 S.CER ECJ0EB1A104K B 105.1/28
C564 4030016930 S.CER ECJ0EB1A104K B 103.2/28
C565 4030016930 S.CER ECJ0EB1A104K B 44/29.9
C566 4030017460 S.CER ECJ0EB1E102K B 42.8/49.5
C567 4030016930 S.CER ECJ0EB1A104K B 42.8/50.4
C568 4030017460 S.CER ECJ0EB1E102K B 67.3/6.6
C569 4550006250 S.TAN TEESVA 1A 106M8R B 89.6/40.7
C573 4030016930 S.CER ECJ0EB1A104K B 34.7/23.7
C574 4030016930 S.CER ECJ0EB1A104K B 62.6/11.9
C575 4510009020 S.ELE EEE0JA331P B 106/11.4
J501 6510019121 S.CNR S8B-PH-SM4-TB (LF) (SN) B 26.9/27.5
J502 6510019121 S.CNR S8B-PH-SM4-TB (LF) (SN) B 52.9/15.1
J503 6450002210 CNR 3017-8821 <KIN>
J504 6510014961 S.CNR B2B-ZR-SM4-TF (LF) (SN) B 18.4/57
DS500 5030002811 LCD L4-0013TVY-2
DS501 5040002710 LED EMPG3338S
DS502 5040002720 LED EMVR3338S
DS503 5040002710 LED EMPG3338S
DS504 5040002720 LED EMVR3338S
DS505 5040002310 S.LED SML-311YTT86 T 111.2/43.2
DS506 5040002310 S.LED SML-311YTT86 T 101.3/43.2
DS507 5040002310 S.LED SML-311YTT86 T 91.3/43.2
DS508 5040002310 S.LED SML-311YTT86 T 81.2/43.1
DS509 5040002310 S.LED SML-311YTT86 T 71.3/43.2
DS510 5040002310 S.LED SML-311YTT86 T 61.3/43.2
DS511 5040002150 LED VRPG3349S-734
DS512 5040002150 LED VRPG3349S-734
