SECTION 1 SPECIFICATIONS
M GENERAL
[FR5000] [FR5100]
• Frequency coverage 136–174 MHz
• Conventional channels max. 32 ch
• Type of emission Wide
16K0F3E
Middle – 14K0F3E
Narrow
11K0F3E/11K0F7E/11K0F7D/11K0F7W
/
8K50F3E ([EXP-01] only)
8K50F3E
Digital 4K00F1E/4K00F1D/4K00F3E
• Antenna impedance 50
Ω
(Nominal)
• Operating temperature range –22˚F to +140˚F (–30˚C to +60˚C) –25˚C to +55˚C
• Power supply requirement
(nominal)
13.6 V DC (Negative ground) 13.2 V DC (Negative ground)
• Current drain (Approx.) Receiving 500 mA (stand-by), 1900 mA (max. audio)
Transmitting 15 A (at 50 W) 8.0 A (at 25 W)
• Dimensions
(Projections not included)
19 (W)×3
15
⁄32 (H)×10
1
⁄4 (D) in. 483 (W)×88 (H)×260 (D) mm
• Weight (Approx.) 12 Ib 5
17
/32 oz. 5.6 kg
M TRANSMITTER
[FR5000] [FR5100]
• Output power 50 W 25 W
• Modulation Variable reactance frequency modulation
• Max. frequency deviation Wide ±5.0 kHz
Middle – ±4.0 kHz
Narrow ±2.5 kHz
• Frequency stability ±0.5 ppm ±0.2 kHz
• Spurious emissions 80 dB typ. 0.25
μ
W (
≤
1 GHz), 1.00
μ
W (
>
1 GHz)
• Adjacent channel power Wide 76 dB typ. 76 dB typ.
Middle – 76 dB typ.
Narrow 69 dB typ. 70 dB typ.
Digital 65 dB typ. 66 dB typ.
• Audio harmonic distortion 1% typ. (at AF 1 kHz 40% deviation)
• Intermodulation attenuation – 40 dB min.
• Audio frequency response +2 dB to –8 dB of 6 dB/oct. Wide/Middle from 300 Hz to 3000 Hz
Narrow from 300 Hz to 2550 Hz
• FM Hum and noise
(300 Hz–3000 Hz, 750 µs)
Wide 52 dB typ.
–
Narrow 49 dB typ.
• Audio input impedance (Microphone) 600
Ω
To Next Page
