5
D 4 digit channels
The 4 digit channels are displayed as shown below.
The channel number is displayed in the channel name
readout (at the bottom right) and the last 2 digits are
displayed in the channel number readout (center).
L The channel name cannot be displayed or entered.
Example: CH 1019
Example: CH 2078
Example: During Dualwatch or
Tri-watch
L The whole channel number
is not displayed.
3
BASIC OPERATION
D USA,Canadian, and international
channels
The IC-M200 has 67 USA, 67 international, and 71
Canadian preset channels.
L These channel groups may be specied for your
operating area. Ask your delaer for details.
1. Push [Ù] and [Ú] on the transceiver at the same
time.
• USA, International, and Canadian channel groups are
selected in sequence.
L “U,” “
,” or “C” is displayed to the left of the channel
number.
2. Push [Ù] or [Ú] to select your desired channel.
L“ ” is displayed when selecting a duplex channel.
and )
Push [U/I/C] (both
■ Selecting a channel (continued)

Icom IC-M200 Specifications

General

Purpose	-
Maximum range	- m
Operating frequency	156.025 - 162.025 MHz
Display type	LCD
Product color	Black
International Protection (IP) code	IPX7
Operating temperature (T-T)	-20 - 60 °C

Weight and Dimensions

Depth	67 mm
Width	153 mm
Height	133 mm
Weight	790 g
