Icom IC-M602 Service Manual

R1 7210002360 VARIABLE TP96N97-15F-10KB-1301
EP1 0910055532 PCB B 5885B
R1 7210003080 VARIABLE TP96N97-15F-10KA-2345
W1 8900011710 CABLE OPC-1186
EP1 0910055522 PCB B 5884B
J1 6510022440 CONNECTOR LTW-8MP-C <LIA>
J2 6510022440 CONNECTOR LTW-8MP-C <LIA>
J3 6510023320 CONNECTOR LTWD-06PMMP-LC <LIA>
J4 6510023090 S.CONNECTOR 20FLT-SM1-TB
J5 6510014960 S.CONNECTOR B2B-ZR-SM3-TF
EP1 0910055492 PCB B 5881B
S1 2250000470 ENCODER EVQ-V9C00116E
W1 8900011720 CABLE OPC-1187
EP1 0910055512 PCB B 5883B
SP1 2510001210 SPEAKER 066P0804 <KS>
W1 8900011470 CABLE OPC-1177 <LIA>
W2 7120000470 JUMPER ERDS2T0
W3 7120000470 JUMPER ERDS2T0
[LOGIC BOARD]
6-1 IC-M602
[SQL BOARD]
S.=Surface mount
IC1 1140010584 S.IC HD64F2633F25 (FX2577A-4)
IC2 1110005770 S.IC S-80942CNMC-G9C-T2
IC3 1130007450 S.IC RTC-4553A
IC4 1140009240 S.IC HN58X24128FPI
IC5 1180002420 S.IC S-818A33AUC-BGN-T2
Q1 1510000580 S.TRANSISTOR 2SA1362-GR (TE85R)
Q2 1590000430 S.TRANSISTOR DTC144EUA T106
Q4 1590000430 S.TRANSISTOR DTC144EUA T106
Q5 1590000430 S.TRANSISTOR DTC144EUA T106
Q6 1590000430 S.TRANSISTOR DTC144EUA T106
Q7 1590000720 S.TRANSISTOR DTA144EUA T106
Q8 1590000430 S.TRANSISTOR DTC144EUA T106
Q11 1590000430 S.TRANSISTOR DTC144EUA T106
Q12 1590000720 S.TRANSISTOR DTA144EUA T106
Q13 1590000720 S.TRANSISTOR DTA144EUA T106
Q15 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q16 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q17 1520000460 S.TRANSISTOR 2SB1132 T100 R
D1 1160000070 S.DIODE DAN202K T146
D2 1750000150 S.DIODE DA204K T146
D3 1750000150 S.DIODE DA204K T146
D4 1750000150 S.DIODE DA204K T146
D5 1730002360 S.ZENER MA8062-M (TX)
D11 1720000360 S.DIODE HSU88TRF
D12 1720000360 S.DIODE HSU88TRF
D13 1720000360 S.DIODE HSU88TRF
D14 1720000360 S.DIODE HSU88TRF
D15 1720000360 S.DIODE HSU88TRF
D16 1720000360 S.DIODE HSU88TRF
D17 1720000360 S.DIODE HSU88TRF
D18 1720000360 S.DIODE HSU88TRF
X1 6050011090 S.XTAL CR-691 (9.8304 MHz)
R1 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R3 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R4 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R5 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R6 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R7 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R8 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R9 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R10 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R12 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R13 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R14 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R15 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R16 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R21 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R22 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R23 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R24 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R25 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R27 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R28 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R29 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R31 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R32 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R33 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R35 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R36 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R37 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R38 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R39 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R40 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R41 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R42 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[VR BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[CONNECT UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[DIAL UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[FRONT UNIT]
REF ORDER
DESCRIPTION
NO. NO.
