Icom IC-M602 Service Manual

SECTION 7 MECHANICAL PARTS AND DISASSEMBLY
7-1 IC-M602
W1 8900011440 Cable OPC-1174 1
P1 6510023310 LTWD-06BFFA-L180 1
P2 6510023300 LTWB-03BFFA-L180 1
MC1 0800006570 HM-136W [WHITE] 1
0800006580 HM-136B [BLACK] 1
MP1 8950005110 2289 mic hanger 1
MP2 8610010561 2040 knob bolt-1 [BLACK] 2
8610011260 2040 knob bolt (B)-1 [WHITE] 2
MP3 8010018860 2455 bracket [BLACK] 1
8010019140 2455 bracket (A) [WHITE] 1
MP4 8310050900 2438 warning sticker 1
MP5 8810001490 Screw PH A M5 × 20 SUS 4
MP6 8850000500 Spring washer M5 SUS 4
MP7 8850000180 Flat washer M5 SUS 4
MP8 8810004700 Screw PH A M3 × 16 SUS 2
MP9 8930059480 Sponge (GZ) 2
[ACCESSORIES]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
J1 6510004880 Antenna connector MR-DS-E 01 1
W1 8900011450 Cable OPC-1175 1
W2 8900011460 Cable OPC-1176 1
MP1 8010019070 2577 chassis 1
MP2 8210019200 2577 rear panel assembly [BLACK] 1
8210019210 2577 rear panel (A) assembly [WHITE] 1
MP3 8930058270 2577 F-packing 1
MP4 8930058260 2577 R-packing 1
MP5 8930058460 2577 bush plate 1
MP6 8110007800 2577 module cover 1
MP7 8930058480 2577 module plate 1
MP8 8510014900 2577 shield cover 1
MP9 8930034300 1542 ANT seal 1
MP10 8930058780 2577 sheet 1
MP11 8810008660 Screw PH BT M3 × 8 NI-ZU 7
MP12 8810008660 Screw PH BT M3 × 8 NI-ZU 3
MP13 8820001210 2438 screw 6
MP14 8820001210 2438 screw 6
MP15 8820001210 2438 screw 2
MP16 8820001210 2438 screw 2
MP17 8810004300 Screw PH M3 × 10 ZK 2
MP19 8930052290 O ring (AD) 8
MP20 8930058450 2577 IC clip 1
MP21 8930058470 2577 IC plate 1
MP22 8930049040 Insulation plate 1
MP23 8930055040 2438 cap 4
MP25 8930059020 Thermally sheet (AI) 1
MP26 8810008660 Screw PH BT M3 × 8 NI-ZU 1
[CHASSIS PARTS]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
W12 7030010860 Jumper MJP-0.6 1
EP3 6910002160 Shield case BM7 1
MP1 8510014870 2577 RX-VCO case 1
MP2 8510014880 2577 TX-VCO case 1
MP3 8510014890 2577 DBM case 1
MP4 8510014890 2577 DBM case 1
MP5 8510015100 2577 shield case 1
MP6 8930059350 2577 earth plate 1
MP7 8930014140 Earth spring (D) 1
[MAIN UNIT]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
W1 8900011470 Cable OPC-1177 1
MP1 8210019180 2577 front panel assembly [BLACK] 1
8210019190 2577 front panel (A) assembly [WHITE] 1
MP12 8610011240 Knob N295 [BLACK] 1
8610011250 Knob N295 (A) [WHITE] 1
MP13 8610011240 Knob N295 [BLACK] 1
8610011250 Knob N295 (A) [WHITE] 1
MP14 8610011210 Knob N293 [BLACK] 1
8610011230 Knob N293 (A) [WHITE] 1
MP17 8810008660 Screw PH BT M3 × 8 NI-ZU 7
MP18 8930059200 O ring (AT) 1
MP19 8930053030 2345 earth plate 1
MP20 8930058900 Rubber sheet (BB) 2
MP21 8850001980 Flat washer M10 1
MP22 8930052280 O ring (AC) 2
[FRONT UNIT]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
S1 2230000250 Switch SPPH22014A 1
BT1 3020000110 Battery CR2032 1
DS1 5030002390 LCD HLM7784-010100 1
MP1 8930058440 2577 LCD holder 1
MP2 8210019060 2577 reflector 1
MP3 8930058910 2577 LCD sheet 1
[LOGIC BOARD]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
S1 2250000470 Switch EVQ-V9C00116E 1
[DIAL BOARD]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
R1 7210003080 Variable resistor TP96N97-15F-10KA-2345 1
[VR BOARD]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
R1 7210002360 Variable resistor TP96N97-15F-10KA-1301 1
[SQL BOARD]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
J1 6510022440 Connector LTW-8MP-C 1
J2 6510022440 Connector LTW-8MP-C 1
J3 6510023320 Connector LTWD-06PMMP-LC 1
[CONNECT UNIT]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
7 - 1
Screw abbreviations BT: Self-tapping PH: Pan head
ZK: Black NI: Nickel
SUS: Stainless NI-ZU: Nickel-Zinc
Accessories illustation is shown at the next page.
