Icom IC-T90A User Manual

19
4
BASIC OPERATION
DSetting the frequency with keypad
q Select VFO mode with [VFO].
w Push the desired numeral buttons until inputting 1 kHz digit to set the frequency.
• When you want to change the 100 kHz digit and below, push [•] first, then the numeral but-
tons.
• Acceptable digits for the 1 kHz digit depend on the 10 kHz digit.
■ Setting a frequency
Push numeral keys and [•] to input the
desired frequency.
•Frequency can be set irrelevant of the se-
lected band.
•When inputting a frequency outside of the
frequency range, the previously selected
frequency is automatically selected after in-
putting 1 kHz digit.
1
V D
2
TONE
3
H/L
4
DUP
5
SKIP
6
M.N
0
RIT
7
T.SCAN
8
SET
9
TS
.
DTMF.M
[VFO]
2
TONE
4
DUP
.
DTMF.M
0
RIT
6
M.N
8
SET
.
DTMF.M
FM
FM
FM
FM
FM
SKIPP
SKIPP
SKIPP
SKIPP
SKIPP
0
RIT
4
DUP
5
SKIP
3
H/L
3
H/L
4
DUP
8
SET
.
DTMF.M
FM
FM
FM
FM
FM
FM
FM
0
RIT
SKIPP
SKIPP
SKIPP
SKIPP
SKIPP
SKIPP
SKIPP
• Setting to 0.684 MHz • Setting to 433.580 MHz • Changing 100 kHz and
below.
Setting 433.580 MHz to
433.240 MHz.
