FITTING THE OPTIONAL ROOF FLUE KIT (Flat or Pitched)
Note.
A at or pitched roof ashing plate (not supplied) is
required before proceeding with the installation of this
kit.
from the top of the boiler and terminating above roof
level.
Connection to the top of the boiler is made using a
separately supplied vertical connector
WEATHER PROOFING
adequate seal must be made. This is achieved by
Flat roof weather collar or Universal weather collar.
ACCESSORIES
extending beyond 1m. These packs contain 1m
extension ducts and may be cut to the desired length.
required. For a full accessories list refer to page 7,
30
ROOF FLUE KIT CONTENTS / OPTIONS
A. Flue assembly with terminal
B. Flue seal collar
C. 3.5x13 screw
D.
weather collar
E. Vertical connector (60/100)
screws
F.
(60/100)
G. 90
o
elbow kit (60/100)
H. 45
o
elbow kit (60/100)
