Table 5: Programmable Zone Types
Value
Zone Type
0 DISABLED
The zone will be disabled. Violation of a disabled zone is ignored.
1 ENTRY/EXIT
Violation of an Entry/Exit zone is ignored during the exit delay period of the arming
procedure. Violating an Entry/Exit zone when armed initiates the entry delay. The entry
delay programmed into location 20 and the exit delay programmed into location 18 will
be used. Failure to exit through an Entry/Exit zone after arming will enable the stay
mode. If a valid user code is not entered before the entry delay period expires, an alarm
condition will be registered. The behaviour of this zone type during the exit delay period
is affected by the value programmed into location 9.
2 FOLLOWER
A Violation of a Follower zone will be ignored during the Entry/Exit Delay period (this
allows the user to enter/exit via the Follower zone). A Follower zone will behave as an
Instant zone if the panel is armed and an Entry/Exit zone is not violated first. The
behaviour of this zone type is affected by the value programmed into location 9.
3
AUDIBLE PRIORITY/PANIC
Regardless of whether the panel is armed or not, a violation of an Audible Priority zone
will cause the control panel to register an alarm condition and sound the siren.
4 AUDIBLE INSTANT
If the panel is armed, the violation of an Instant zone will cause the control panel to
immediately register an alarm condition. The behaviour of the siren will depend upon
the value programmed into location 15. While the panel is unarmed, a violation of an
Instant zone is ignored.
5 ARM/DISARM
A violation of an Arm/Disarm zone will cause the panel to arm or disarm. To use this
facility, connect a momentary key-switch or non-latching remote control unit to this
zone. The end-of-line resistor will still be required.
6 SILENT PRIORITY
Regardless of whether the panel is armed or not, a violation of a Silent Priority zone will
not cause the siren to sound but will report the appropriate code programmed into the
relevant program locations to the central station.
7
SILENT INSTANT
If the panel is armed, the violation of a Silent zone will cause the control panel to
immediately register an alarm condition. The siren will not sound. While the panel is
unarmed, the violation of a Silent Instant zone is ignored. This zone is not affected by
the value programmed into location 15.
8 SECONDARY ENTRY/EXIT
The Secondary Entry Delay (see location 10) will be used when this zone is violated
while the panel is armed. When entering the premises, and if a Secondary Entry/Exit
zone is violated after a Primary Entry/Exit has been violated the panel will continue to
countdown the Primary Entry Delay.
10
FIRE ZONE
Violation of a Fire zone will cause the siren to sound regardless of whether the panel is
armed or not. The siren will sound intermittently (one second on, one second off). A
programmable output programmed as a fire detector power output (see location 37)
will also be activated.
12 PUSH TO ARM
If the value in location 18 is 15, once the exit delay has commenced, a violation of the
Push to Arm zone will immediately arm the panel.
