IDS 805 Installer Manual 700-266-02H Issued September 2009
1. Introduction to the IDS 805
The IDS 805 is a versatile, state of the art, microprocessor based, eight-zone Alarm Panel. Most features
are optional and may be programmed either directly through the keypad or via the telephone system,
using the IDS download software and appropriate modem. There are eight programmable burglary
zones, appropriate siren, auxiliary power outputs and 5 outputs which may be programmed to perform
various trigger/switching functions.
For correct operation, the IDS 805 must be used in conjunction with the specified transformer/battery
combination and appropriate peripheral sensors and signalling devices.
1.1 Features
Bylaw 25 compliant
Four wire keypad operation - up to a maximum of 4 keypads.
Eight, fully programmable, end-of-line (3K3) supervised zones, and 1 dedicated panic zone per
keypad which is not end-of-line supervised.
Telephone line and siren monitoring.
Optional tamper and box tamper reporting per zone using double end-of-line resistors (12K and
4K7).
Fully programmable digital telephone communicator which supports most industry standard
formats.
Five programmable trigger outputs.
Non-volatile EEPROM memory retains all program and event log data in the event of a total
power failure.
Programmable loop response time for all zones (global).
Up and downloadable using IDS windows based software.
Excellent protection against lightning (provided by specialised zap tracking and transient
suppressors).
Auto arm - panel can be programmed to arm daily at a predetermined time.
Event log (200 events) date and time stamped.
Fax defeat allows download access to the panel with other devices connected to the phone line.
Dual reporting provides for duplicated reporting to two independent central base stations.
Programmable silent or audible panic.
Unique dialler progress bar allowing for monitoring of dialler status.
